Product details
RGBWW LED Candle Bulb With Base
LumaCircuit offers RGBWW LED Candle Bulb With Base as a configurable bulb for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Working Voltage: -240V, 50/60Hz Color Temperature, Brightness, And Saturation Adjustable Color Temperature: 2700 K- 6500 K The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller RGBWW LED candle bulb has an base with aluminum housing for fast heat dissipation and a PC lens for high light transmittance. The working voltage from AC100V to AC240V can be directly connected to the public power system and replaced with the traditional lamps with an base. Compatible with wireless controller RGB+CCT RF remote controls to adjust the colors, saturation, color temperature, and brightness.
- Working Voltage: -240V, 50/60Hz
- Color Temperature, Brightness, And Saturation Adjustable
- Color Temperature: 2700 K- 6500 K
- Luminous Efficiency: 75LM/W
- Compatible With wireless controller RF Remote Controls T4,
- Support Smartphone APP Control And Third-Party Voice Control(WL- 2.4G Gateway Needed)
- Signal Transmitting And Modes Synchronization
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: RGB+CCT
- Material: Aluminum + PC
- Size: 110*37.5mm(L*W)
- Working Voltage: -240V, 50/60Hz
- Power: 4W
- Color: RGB+CCT
- Color Temperature: 2700 K- 6500 K
- CRI: >
- Beam Angle: 180°
- Control Distance: ≤30m
- Compatible With wireless controller RF Remote Controls: T4,
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller RGBWW LED candle bulb has an base with aluminum housing for fast heat dissipation and a PC lens for high light transmittance. The working voltage from AC100V to AC240V can be directly connected to the public power system and replaced with the traditional lamps with an base. Compatible with wireless controller RGB+CCT RF remote controls to adjust the colors, saturation, color temperature, and brightness. There are 16 million colors and saturation changes to meet various scenes, and the color temperature is adjustable from warm white(2700K) to cool white(6500K). The wireless controller 4W candle bulb supports smartphone apps and third-party voice control after adding a 2.4G gateway, which supports Amazon Alexa and Google Assistant voice commands. The bulbs will receive signals from the remote controls or the app and transmit to other candle lamps within 30m, and different candle lights can work synchronously when they are started at various times. Group the lamps with a remote or app; each zone is controlled independently. Using a smartphone, the installer can also use the 4G network to control the candle bulbs from any place and at any time.
Specifications
Material: Aluminum + PC
Size: 110*37.5mm(L*W)
Working Voltage: -240V, 50/60Hz
Base
Power: 4W
Color: RGB+CCT
16 Million Colors Available
Color Temperature, Brightness, And Saturation Adjustable
Color Temperature: 2700 K- 6500 K
Luminous Flux: 300LM
Luminous Efficiency: 75LM/W
CRI: >
Beam Angle: 180°
Control Distance: ≤30m
Compatible With wireless controller RF Remote Controls T4,
Support Smartphone APP Control And Third-Party Voice Control(WL- 2.4G Gateway Needed)
Signal Transmitting And Modes Synchronization
Group Control
4G Controlling At Any Place And Any Time（2.4G Gateway Needed)
Includes
1 * wireless controller RGBWW LED Candle Bulb
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
