Product details
4G Controllable 4W RGB+CCT Bulbs
LumaCircuit offers 4G Controllable 4W RGB+CCT Bulbs as a configurable bulb for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Size(L*W): 80*46mm/3.15"*1.81" Working Voltage: -240V, 50/60Hz Emitting Color: RGB + CCT The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller RGB+CCT bulbs are smart bulbs that can be controlled using a smartphone app and voice commands to select colors, adjust brightness, and adjust color temperature for various scenes. The utilizes imported LED chips as its light source and features a high-transmittance cover on the outside. Additionally, and lamp bases are available.
- Size(L*W): 80*46mm/3.15"*1.81"
- Working Voltage: -240V, 50/60Hz
- Emitting Color: RGB + CCT
- Color Temperature Adjustable: 2700 K- 6500 K
- Luminous Efficiency: 95LM/W
- Can Be Controlled By wireless controller Or 2.4 GHz wireless RGB+CCT Remote Controls B, B, B, B, T3, B, T4, B, W, G, WL
- Auto signal transmitting and mode synchronization
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: RGB+CCT
- LumaCircuit model: LC-BLB-SF1RQK
- Material: Aluminum + PC
- Size(L*W): 80*46mm/3.15"*1.81"
- Working Voltage: -240V, 50/60Hz
- Power: 4W
- Emitting Color: RGB + CCT
- Color Temperature Adjustable: 2700 K- 6500 K
- CRI: >
- Beam Angle: 220°
- Control Distance: 30m
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller RGB+CCT bulbs are smart bulbs that can be controlled using a smartphone app and voice commands to select colors, adjust brightness, and adjust color temperature for various scenes. The utilizes imported LED chips as its light source and features a high-transmittance cover on the outside. Additionally, and lamp bases are available. The wireless controller LED lamps integrate a 2.4G communication protocol, which can be controlled by wireless controller or 2.4 GHz wireless RGB CCT remote controls to turn ON/OFF, change the color, and adjust the color temperature and brightness for various scenes. There are 16 million colors available, the color temperature can be adjusted from 2700K to 6500K, and the brightness can be adjusted from 1% to 100%. The RGB CCT LED bulbs will receive signals from the remote control and transmit them to the same model lamps within a 30-meter range. All of them can work synchronously when they are started at different times, controlled by the same remote, and under the same dynamic mode. The remote control lights support smartphone apps and third-party voice control after pairing with a 2.4 GHz gateway, and they can work with Amazon Alexa and Google Assistant. The installer can use the APP to achieve more functions like timer, scene customization, etc.
Specifications
Model
Material: Aluminum + PC
Size(L*W): 80*46mm/3.15"*1.81"
Lamp Base
Working Voltage: -240V, 50/60Hz
Power: 4W
Emitting Color: RGB + CCT
Color Temperature Adjustable: 2700 K- 6500 K
Luminous Flux: 340LM
Luminous Efficiency: 95LM/W
CRI: >
Beam Angle: 220°
Control Distance: 30m
IP Rate: IP20
Can Be Controlled By wireless controller Or 2.4 GHz wireless RGB+CCT Remote Controls B, B, B, B, T3, B, T4, B, W, G, WL
Auto signal transmitting and mode synchronization
Smartphone app control and third-party voice control(2.4G gateway needed)
Can work with Amazon Alexa and Google Assistant
Working Temperature: -10℃-+40℃
Applications
Living room ambiance
Bedroom mood lighting
Parties & holiday decor
Smart home automation
Includes
1 * bulb
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
