Product details
RF Dual White LED Candle Lamp
LumaCircuit offers RF Dual White LED Candle Lamp as a configurable bulb for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Working Voltage: -240V, 50/60Hz Color Temp: 2700 K- 6500 K Luminous Efficiency: 100LM/W The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller dual white LED candle lamp adopts 2.4G transmission technology and can be controlled by 2.4G RF remote controls, which are compatible with wireless controller CCT remote controls. The installer can adjust the color temperature from 2700K to 6500K and the brightness without flickering. After adding a 2.4G gateway, a Smartphone APP, and Third-Party Voice, the installer can control the candle light, which supports Amazon Alexa and Google Assistant.
- Working Voltage: -240V, 50/60Hz
- Color Temp: 2700 K- 6500 K
- Luminous Efficiency: 100LM/W
- 4G RF Remote Controls Controllable
- Compatible With wireless controller CCT Remote Controls T2
- Support Smartphone APP Control And Third-Party Voice Control(2.4G Gateway Needed)
- Color Temperature Adjustable From 2700K To 6500K
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: CCT
- Material: Aluminum + PC
- Size: 110*37.5mm(L*W)
- Working Voltage: -240V, 50/60Hz
- Power: 4W
- Color: Tunable White
- Color Temp: 2700 K- 6500 K
- CRI: >
- Beam Angle: 180°
- Control Distance: ≤30m
- Compatible With wireless controller CCT Remote Controls: T2
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller dual white LED candle lamp adopts 2.4G transmission technology and can be controlled by 2.4G RF remote controls, which are compatible with wireless controller CCT remote controls. The installer can adjust the color temperature from 2700K to 6500K and the brightness without flickering. After adding a 2.4G gateway, a Smartphone APP, and Third-Party Voice, the installer can control the candle light, which supports Amazon Alexa and Google Assistant. The installer can control the lamps with your smartphone through the 4G network anywhere and anytime. One candle lamp will receive the Signals and transmit them to other lamps within 30 meters; all will have the same lighting status. The installer can group the Lamps with a remote or smartphone; each zone is controlled independently. The wireless controller CCT candle lamps have aluminum housing for fast heat dissipation and a PC Cover for high light transmittance.
Specifications
Material: Aluminum + PC
Size: 110*37.5mm(L*W)
Working Voltage: -240V, 50/60Hz
Power: 4W
Color: Tunable White
Color Temp: 2700 K- 6500 K
Luminous Flux: 400LM
Luminous Efficiency: 100LM/W
CRI: >
Beam Angle: 180°
RF: 2.
Control Distance: ≤30m
4G RF Remote Controls Controllable
Compatible With wireless controller CCT Remote Controls T2
Support Smartphone APP Control And Third-Party Voice Control(2.4G Gateway Needed)
Color Temperature Adjustable From 2700K To 6500K
Signal Transmitting
Group Control
4G Controlling At Any Place And Any Time(2.4G Gateway Needed)
Working Temp: -10℃-+40℃
Includes
1 * wireless controller Tunable White LED Candle Lamp
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
