720W RGB LED Controller With RF Wireless Touch Wall Panel Remote
LumaCircuit offers 720W RGB LED Controller With RF Wireless Touch Wall Panel Remote as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Working Temperature: -20℃-60℃ Working Voltage: DC12V-DC24V Static Power Consumption: <1W The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The RGB LED controller has the Ports for the sync-work, multiple controllers can work synchronically when connected by network cable through the connectors, the network cable between 2 ports up to the installer can use the first LED controller as the master control to adjust the brightness or change the dynamic mode, all of LED Light will change synchronically. The RGB LED controller is designed for the constant voltage LED light, working in DC12V or DC24V, with 3 output channels.
- Working Temperature: -20℃-60℃
- Working Voltage: DC12V-DC24V
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Max Output Current: 10A Each Channel
- Max Output Power: 360W(DC12V) / 720W(DC24V)
- With Ports For Sync-Work Function
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 24 V
- Light engine: RGB
- Size: * * mm
- Working Temperature: -20℃-60℃
- Working Voltage: DC12V-DC24V
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Output: 3 Channels
- Max Output Current: 10A Each Channel
- Max Output Power: 360W(DC12V) / 720W(DC24V)
- Modes: 9
- PWM Frequency: 433.
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The RGB LED controller has the Ports for the sync-work, multiple controllers can work synchronically when connected by network cable through the connectors, the network cable between 2 ports up to the installer can use the first LED controller as the master control to adjust the brightness or change the dynamic mode, all of LED Light will change synchronically. The RGB LED controller is designed for the constant voltage LED light, working in DC12V or DC24V, with 3 output channels. The max output current of each channel is 10A, and the max loading power is up to 720W when working in DC24V comes with the touch wall panel remote control, which works in AC90V-265V, the installer can connect it to the AC110V or AC220V power system directly, without needing an extra LED Driver. The remote's structure, dimensions, and installation are according to the 86-type European standards, making it easy to install and use. The installer can use the Remote to adjust the brightness of static color, 256 levels; the speed of dynamic changes is adjustable, 100 levels in total. Long-press the brightness and speed key to get fast adjustment and convenience for operation. Each time powered on, the LED RGB controllers with memory function reserve the mode that was stopped at the last power off.
RGB LED Controller Specifications
Size: * * mm
Working Temperature: -20℃-60℃
Working Voltage: DC12V-DC24V
Static Power Consumption: <1W
Connecting Mode: Common Anode
Grayscale: 256 Levels
Speed Stage: 100 Grade
Output: 3 Channels
Max Output Current: 10A Each Channel
Max Output Power: 360W(DC12V) / 720W(DC24V)
RF Distance: <20M
PWM Frequency: 433.
With Ports For Sync-Work Function
Multiple Controllers Can Work Synchronically When Connected By Network Cable Ports
Long Long-press the Brightness And Speed Key Can Get The Fast Adjustment
Brightness Of Static Colors Adjustable, And Speed Of Dynamic Modes Adjustable
Memory Function: YES
Short Circuit Protection: YES
Weight: 300g
Wireless Wall Panel Remote Specifications
Size: 86*86*34mm(L*W*H)
Working Temperature: 0℃-45℃
Working Voltage: -265V(50/60Hz)
Standby Power: 0.2W
Working Power: 2W
RF Frequency: 433.
RF Distance: <20M
Structure Dimension Installation According To The 86-Type European Standards
Weight: 130g
Includes
1 * RGB LED Controller With Port
1 * RF Wireless Touch Wall Panel Remote
