4G 288W Mini LED WIFI Light Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The mini LED WiFi light controller supports Android and IOS platform, like phone, tablets, PC, it controls LED products through WiFi, the installer can install the software on them, which makes LED control more intelligent and humanization, with 3 in 1 function design, the mini LED WiFi controller can be used as A dimmer, CCT controller and RGB controller, only need to select the right control interface in the software, the mini WiFi controller with DIY function, user can set the function and save.
• Size: 106*45*23mm(L*W*H)
• Connecting Method: Common Anode
• Working Voltage: DC12V-DC24V
• Output Current: ≤4A(Each Channel)
• Output Wattage: DC12V:≤144W; DC24V:≤288W
• WIFI Working Frequency: 2.4G
• Working Temperature: -20- 60 °C

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12 V / 24 V
• Light engine: RGB
• Size: 106*45*23mm(L*W*H)
• Working Voltage: DC12V-DC24V
• Output Channels: 3
• Output Current: ≤4A(Each Channel)
• Output Wattage: DC12V:≤144W; DC24V:≤288W
• Power Consumption: <3W
• WIFI Working Frequency: 2.4G
• Output Gray Level: 256
• Working Temperature: -20- 60 °C
• Working Platform: Android/IOS(With wifi function)

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The mini LED WiFi light controller supports Android and IOS platform, like phone, tablets, PC, it controls LED products through WiFi, the installer can install the software on them, which makes LED control more intelligent and humanization, with 3 in 1 function design, the mini LED WiFi controller can be used as A dimmer, CCT controller and RGB controller, only need to select the right control interface in the software, the mini WiFi controller with DIY function, user can set the function and save. This WIFI LED light controller can work with constant voltage, LED strips, LED modules, and other LED products. Order the extra LED light amplifier if you want to control more LED products. The installer can also purchase the 2.4G RF remote control separately for the LED WiFi controller. The WiFi controller with a 3-output-channel design, the max output current of each channel is 4A, the max loading power is up to 288W when working in DC24V.

Specifications

Size: 106*45*23mm(L*W*H)

Connecting Method: Common Anode

Working Voltage: DC12V-DC24V

Output Channels: 3

Output Current: ≤4A(Each Channel)

Output Wattage: DC12V:≤144W; DC24V:≤288W

Power Consumption: <3W

WIFI Working Frequency: 2.4G

Output Gray Level: 256

Working Temperature: -20- 60 °C

WIFI Brightness level: 100

WIFI Speed Level: 100

Receiving Sensitivity: 802.:DSSS（-）802.:CCK802.11g:OFDM

Working Platform: Android/IOS(With wifi function)

Weight: 100g

1 * LED WiFi Light LED Controller
