4 In 1 48V Constant Current RF LED Controller
LumaCircuit offers 4 In 1 48V Constant Current RF LED Controller as a configurable LED controller for project builds. Typical applications include CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Working Temperature: -20℃-45℃ Size: 160*46*25mm(L*W*H) Static Power Consumption: <1W The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The constant current RF LED controller has a 4 in 1 function design for CCT/RGB/RGBW LED lighting. The RF controller adopts the most advanced PWM digital control technology, which the installer can use to control most constant current LED lights. The working voltage range is between DC12V and DC48V. The input interface includes the V+ extremely common interface, and the other four are for the 4-channel output control interface. The installer can connect to the single color, tunable white, RGB, and RGBW LED stipes.
- Working Temperature: -20℃-45℃
- Size: 160*46*25mm(L*W*H)
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Input Voltage Range: DC12V-48V
- Output Current Range: 300
- Max Output Power: 36W(12V), 72W(24V), 168W(48V)
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12-48 V / 12 V / 48 V / 24 V
- Light engine: RGBW
- Working Temperature: -20℃-45℃
- Size: 160*46*25mm(L*W*H)
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Input Voltage Range: DC12V-48V
- Output Voltage Range: 6
- Output Channels: 4
- Output Current Range: 300
- Max Output Power: 36W(12V), 72W(24V), 168W(48V)
- RF Frequency: 2.
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The constant current RF LED controller has a 4 in 1 function design for CCT/RGB/RGBW LED lighting. The RF controller adopts the most advanced PWM digital control technology, which the installer can use to control most constant current LED lights. The working voltage range is between DC12V and DC48V. The input interface includes the V+ extremely common interface, and the other four are for the 4-channel output control interface. The installer can connect to the single color, tunable white, RGB, and RGBW LED stipes. There is a DIP switch that allows controlling the output type. The installer can also control the output current by pressing another DIP switch on the RF LED controller; the output current ranges from to the 2. LED light remote included, no need for line-of-sight, the control range up to the installer can use the RF remote control to set the various static colors or dynamic modes for the perfect control effect, and it supports 1024 static colors(RGB/RGBW) and a soft dim function. The brightness of static color is adjustable, 1024 levels in total, and the speed of dynamic changes is adjustable too, 1024 levels in total. Long-press the brightness and speed keys to get the fast adjustment.
LED RF Controller Specifications
Working Temperature: -20℃-45℃
Size: 160*46*25mm(L*W*H)
Static Power Consumption: <1W
Connecting Mode: Common Anode
Input Voltage Range: DC12V-48V
Output Voltage Range: 6
Output Channels: 4
Output Current Range: 300
Max Output Power: 36W(12V), 72W(24V), 168W(48V)
Grayscale: 1024 Levels
Speed Stage: 100 Grade
RF Frequency: 2.
RF Control Distance: ≤20m
4 In 1 Function: DIM, CCT, RGB, RGBW
Input Voltage Range: -48V, Output Current Range: From to By DIP Switch
4G Wireless RF Remote Control Included
Wireless-Sync-Control Function Available In Both Static Colors And Dynamic Modes
Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable
Short Circuit Protection: YES
Memory Function: YES
Weight: 135g
Wireless Remote Control Specifications
Working Temperature: -20℃-60℃
Size: 150*40*20mm(L*W*H)
Working Voltage: DC3V(AAA*2)
Standby Current: <
Working Current: <
Standby Power
Working Power
RF Frequency: 2.
RF Distance: ≤20m
Weight: 95g
Includes
1 * 4 In LED Controller
1 * 2.4G RF Wireless Remote Control
Typical applications
- CCT and RGB+CCT rooms
- Retrofit dimming
- Home Assistant lighting zones
