720W RGB Light Controller With 20 Keys RF Remote Control
LumaCircuit offers 720W RGB Light Controller With 20 Keys RF Remote Control as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Working Temperature: -20-60℃ Working Voltage: DC12V-24V Output Current: <10A ( Each Channel ) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The RGB light controller is enclosed in a black metal shell for better heat dissipation. It works on DC12V or DC24V, with a 3-channel output design. The max output current of each channel can reach 8A, and the max loading power is up to 720W when working in DC24V. The LED RGB controller with the advanced micro control unit can control various LED lights, point source lights, LED light strips, etc.
- Working Temperature: -20-60℃
- Working Voltage: DC12V-24V
- Output Current: <10A ( Each Channel )
- Output Power: 360W ( 12V ) / 720W ( 24V )
- Connecting Mode: Common Anode
- Static Power Consumption: <1W
- Adopts Dual Network Cable Ports
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 24 V
- Light engine: RGB
- Size: 91*88*24mm(L*W*H)
- Working Temperature: -20-60℃
- Working Voltage: DC12V-24V
- Output: 3 Channels
- Output Current: <10A ( Each Channel )
- Output Power: 360W ( 12V ) / 720W ( 24V )
- Connecting Mode: Common Anode
- Static Power Consumption: <1W
- RF Frequency: 433.
- LumaCircuit model: LC-CTL-23DDPH
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The RGB light controller is enclosed in a black metal shell for better heat dissipation. It works on DC12V or DC24V, with a 3-channel output design. The max output current of each channel can reach 8A, and the max loading power is up to 720W when working in DC24V. The LED RGB controller with the advanced micro control unit can control various LED lights, point source lights, LED light strips, etc. Comes with RF remote control, which has 14 modes in total, 8 static colors, and 6 dynamic modes, and can use the remote to adjust the brightness of the static colors and speed of dynamic modes. The LED RGB control adopts dual network cable ports, which makes it convenient to use the port to connect multiple controllers together to achieve the synchronization function of many RGB LED lights.
Specifications
Size: 91*88*24mm(L*W*H)
Working Temperature: -20-60℃
Working Voltage: DC12V-24V
Output: 3 Channels
Output Current: <10A ( Each Channel )
Output Power: 360W ( 12V ) / 720W ( 24V )
Connecting Mode: Common Anode
Static Power Consumption: <1W
Adopts Dual Network Cable Ports
RF Remote Included
RF Frequency: 433.
14 Modes In Total, 8 Static Colors And 6 Dynamic Modes
Weight: 270g
Includes
1 * RGB Light Controller
1 * 20 Keys RF Remote Control
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
