4 IN 1 Wireless Sync Controller With Remote For RGBW LED Lights
LumaCircuit offers 4 IN 1 Wireless Sync Controller With Remote For RGBW LED Lights as a configurable LED controller for project builds. Typical applications include CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Size: 160*46*25mm(L*W*H) Working Voltage: DC12V-24V Connecting Mode: Common Anode The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless sync controller for LED lights with a 4-In-1 design can be used for single color, tunable white, RGB, and RGBW. The wireless LED controller adopts the most advanced PWM digital control technology for controlling constant voltage strip lights, LED lamps, point-source lights, LED modules, and LED strings. It has a low-voltage DC input and 5 output interfaces, working on DC12V or DC24V. There is a DIP switch for LED color type selection. 4 options are available: RGB, RGBW, DIM, and CCT.
- Size: 160*46*25mm(L*W*H)
- Working Voltage: DC12V-24V
- Connecting Mode: Common Anode
- Output Current: ≤6A Each Channel
- Max Output Power: 288W ( 12V ) / 576W ( 24V )
- Static Power Consumption: <1W
- Working Temperature: -20-60℃
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 24 V
- Light engine: RGBW
- LumaCircuit model: LC-CTL-I66L0W
- Size: 160*46*25mm(L*W*H)
- Working Voltage: DC12V-24V
- Connecting Mode: Common Anode
- Output: 4 Channels
- Output Current: ≤6A Each Channel
- Max Output Power: 288W ( 12V ) / 576W ( 24V )
- RF Frequency: 2.
- Static Power Consumption: <1W
- Working Temperature: -20-60℃
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless sync controller for LED lights with a 4-In-1 design can be used for single color, tunable white, RGB, and RGBW. The wireless LED controller adopts the most advanced PWM digital control technology for controlling constant voltage strip lights, LED lamps, point-source lights, LED modules, and LED strings. It has a low-voltage DC input and 5 output interfaces, working on DC12V or DC24V. There is a DIP switch for LED color type selection. 4 options are available: RGB, RGBW, DIM, and CCT. Please ensure the DIP switch is correct according to the loading LED type. The RF remote control is included, which is powered by 2 AAA batteries and works on DC3V. The installer can use the RF remote to adjust the brightness and color temperature or choose the static color or dynamic mode. The brightness of the static color is adjustable, with 1024 levels in total. The speed of dynamic changes is adjustable, with 100 levels in total. Each time powered on, the wireless RGB LED controller with memory function remembers the mode that was stopped last. The remote has a 4-zone design; the installer can press the "Zone" button to select the zone and control the zones separately, or long-pressing goes to overall control.
Sync RGB LED Controller Specifications
Model: HX
Size: 160*46*25mm(L*W*H)
Working Voltage: DC12V-24V
Connecting Mode: Common Anode
Output: 4 Channels
Output Current: ≤6A Each Channel
Max Output Power: 288W ( 12V ) / 576W ( 24V )
RF Frequency: 2.
RF Distance: ≤20m
Static Power Consumption: <1W
Grayscale: 1024 Levels
Speed Stage: 1024
PWM Frequency
Memory Function: Yes
Working Temperature: -20-60℃
Short Circuit Protection
Wireless RF Remote Specifications
Model: HX-RFBK-RGB-2.4G
Size: 150*40*20mm(L*W*H)
Working Voltage: DC3V ( AAA*2 )
Standby Current: <
Working Current: <
Standby Power
Working Power
RF Distance: <20m
RF Frequency: 2.
Working Temperature: -20℃-60℃
Includes
1 * Sync RGB LED Controller
1 * Wireless Remote Control
Typical applications
- CCT and RGB+CCT rooms
- Retrofit dimming
- Home Assistant lighting zones
