RGB/RGBW/RGB+CCT 3 in 1 Panel Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller panel controller is designed for RGB, RGBW, and RGB+CCT LED strip lights. The LED panel controller with a high-precision capacitive touch screen is very stable; when touching the buttons, the LED indicating lamp will flash once with a different sound. The installer can touch the buttons to turn On/Off, change the static color or dynamic mode, adjust the brightness of the static color, or change the speed of dynamic mode.
• Output Max Current: 5A/Channel
• Total Output Current: 10A
• Designed For RGB/RGBW/RGB+CCT LED Light Strips
• 16 Million Of Colors To Choose
• Dimmable Saturation Control
• Color Temperature Adjustable
• wireless controller Manual

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: RGB+CCT
• Size: 86*86*26mm(L*W*H)
• Working Voltage: -24V
• Output Max Current: 5A/Channel
• Total Output Current: 10A
• Control Distance: ≤30M
• Working Temperature: -20℃-+60℃
• LumaCircuit model: LC-CTL-U66SC2
• Dimensions found: 86x86x26mm / 26mm / 30M

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller panel controller is designed for RGB, RGBW, and RGB+CCT LED strip lights. The LED panel controller with a high-precision capacitive touch screen is very stable; when touching the buttons, the LED indicating lamp will flash once with a different sound. The installer can touch the buttons to turn On/Off, change the static color or dynamic mode, adjust the brightness of the static color, or change the speed of dynamic mode. Sixteen million colors are adjustable, 2700K to 6500K color temperature is adjustable, and there are 12 dynamic modes available, and the installer can use the remote control to switch. The 2 remote control is sold separately. After adding the 2 gateway( WL ), the wireless controller will support smartphone apps and third-party voice control; the installer can use your phone or voice to control the LED light. The panel LED controller will receive the signal from the remote control and transmit it to another controller within 30 meters. Different controllers can work synchronously when they are started at other times, controlled by the same remote, under the same dynamic mode, and within a 30m distance.

Quick Links

wireless controller Manual

Specifications

Size: 86*86*26mm(L*W*H)

Working Voltage: -24V

Output Max Current: 5A/Channel

Total Output Current: 10A

RF: 2.

Control Distance: ≤30M

Designed For RGB/RGBW/RGB+CCT LED Light Strips

16 Million Of Colors To Choose

Dimmable Saturation Control

Color Temperature Adjustable

4G RF Wireless Transmission Technology

Smartphone APP Control(2. Gateway Needed)

Supports Third-Party Voice Control(2. Gateway Needed)

DMX512 Controllable(DMX512 LED Transmitter Needed)

High Frequency And Low Frequency(500Hz) Can Be Switched According To Needs

Signal Transmitting

Modes Synchronization

Compatible With T3, T4, WL

Working Temperature: -20℃-+60℃

Includes

1 * wireless controller Panel Controller
