X1 Monochrome DMX512 Dimmer 230V

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller X1 monochrome DMX512 dimmer, which has a standard European 86-type structure and works in high voltage AC100V to AC240V, is easy to install and use. The DMX dimmer has a sensitive touch panel design. The LED indicator light will flash with different sounds when touching the buttons. The DMX dimmer complies with DMX512, DMX512-1990, DMX512-A, and RDM.0 protocols.
• wireless controller X1 DMX512 Dimmer Manual
• Working Voltage: -240V, 50/60Hz
• Output Signals: DMX512 + 2.4G Wireless
• RF Transmitting Power: 6 dBm
• RF Control Distance: ≤30m
• Comply With DMX512, -1990, DMX512-A, RDM.0 Protocols
• 1%-100% Brightness Adjustable

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 230 V / 240 V
• Size: 86*86*26mm(L*W*H)
• Working Voltage: -240V, 50/60Hz
• Output Signals: DMX512 + 2.4G Wireless
• RF Transmitting Power: 6 dBm
• RF Control Distance: ≤30m
• Working Temperature: -20-45℃
• LumaCircuit model: LC-CTL-TC4N7F
• Dimensions found: 86x86x26mm / 26mm / 30m

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller X1 monochrome DMX512 dimmer, which has a standard European 86-type structure and works in high voltage AC100V to AC240V, is easy to install and use. The DMX dimmer has a sensitive touch panel design. The LED indicator light will flash with different sounds when touching the buttons. The DMX dimmer complies with DMX512, DMX512-1990, DMX512-A, and RDM.0 protocols. With 2 output signals, the DMX512 signal and 2.4G signal, the installer can control the DMX512 Lamps and 2.4G wireless controller series lamps. The installer can touch the slider to adjust the brightness from 1% to 100%. There are 4 zones individually controlled, and the installer can control each zone separately. There is a 60-second delay OFF function. The installer can use it to control the LED light turn-off delay, which will turn off after 60 seconds. The wireless controller X1 can be controlled by the 2.4G wireless controller RF remote controls and smartphone APP after adding the WL- gateway.

Quick Links

wireless controller X1 DMX512 Dimmer Manual

Specifications

Size: 86*86*26mm(L*W*H)

Working Voltage: -240V, 50/60Hz

Output Signals: DMX512 + 2.4G Wireless

RF Transmitting Power: 6 dBm

RF Control Distance: ≤30m

Comply With DMX512, -1990, DMX512-A, RDM.0 Protocols

1%-100% Brightness Adjustable

4 Zones Individually Controlled

Delay OFF Design

Compatible With wireless controller 2.4G Remote Control

Support Smartphone APP Control(WL- Gateway Needed)

With Sensitive Touching Panel Design

Working Temperature: -20-45℃

Includes

1 * wireless controller Monochrome DMX512 Dimmer
