Wireless Wall Panel 2.4G 4 Zones Touch LED Dimmer Switch
LumaCircuit offers Wireless Wall Panel 2.4G 4 Zones Touch LED Dimmer Switch as a configurable LED controller for project builds. Typical applications include Low-voltage LED systems, Controller and strip power, Signage and display BOMs. 48V Constant Current RF LED Controller For DIM/CCT/RGB/RGBW Working Temperature: -20℃-60℃ Working Voltage: -265V(50/60Hz) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless wall panel touch LED dimmer switch features a 4-zone design, a working voltage range of AC90V to AC265V, and direct connection to the public power system without an extra adapter. The LED touch switch's structure, dimensions, and installation methods are compatible with European standards, and the complete touch panel design features a unique, easy-to-use interface. The touch-dimmer switch supports 4 separate or overall control zones and 4 scene controls.
- 48V Constant Current RF LED Controller For DIM/CCT/RGB/RGBW
- Working Temperature: -20℃-60℃
- Working Voltage: -265V(50/60Hz)
- Remote Control Distance: ≤20m
- Full Touch Panel Design, unique Interface
- 4 Zone Separately Control Overall Control, Support 4 Scenes Control
- Structure Dimension Installation Methods Are In Line With European Standards
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 5 V
- Working Temperature: -20℃-60℃
- Size: 86*86*33mm(L*W*H)
- Working Voltage: -265V(50/60Hz)
- Standby Power: <0.2W
- Working Power: <2W
- Frequency: 2.
- Remote Control Distance: ≤20m
- LumaCircuit model: LC-CTL-N512HB
- Dimensions found: 86x86x33mm / 33mm / 20m
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Low-voltage LED systems, Controller and strip power, Signage and display BOMs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless wall panel touch LED dimmer switch features a 4-zone design, a working voltage range of AC90V to AC265V, and direct connection to the public power system without an extra adapter. The LED touch switch's structure, dimensions, and installation methods are compatible with European standards, and the complete touch panel design features a unique, easy-to-use interface. The touch-dimmer switch supports 4 separate or overall control zones and 4 scene controls. The group control function is intuitive and concise, and the key touches with a buzzer to remind. The Hoion LED dimmer switch uses a 2.4 GHz wireless control module, which offers a long, non-directional control distance. Can work with Hoion dimming drivers.
Quick Links
48V Constant Current RF LED Controller For DIM/CCT/RGB/RGBW
Specifications
Working Temperature: -20℃-60℃
Size: 86*86*33mm(L*W*H)
Working Voltage: -265V(50/60Hz)
Standby Power: <0.2W
Working Power: <2W
Frequency: 2.
Remote Control Distance: ≤20m
Dimming Grade: 1024
Full Touch Panel Design, unique Interface
4 Zone Separately Control Overall Control, Support 4 Scenes Control
Structure Dimension Installation Methods Are In Line With European Standards
Compatible With HD/QD/DLC Series Dimming Drivers
Weight: 170g
Includes
1 * Wall Panel Dimmer Switch For LED Lights
Typical applications
- Low-voltage LED systems
- Controller and strip power
- Signage and display BOMs
