4G RF Single Color LED Dimmer Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller LED dimmer controller is designed for single-color LED strips. Working on DC12V and DC24V, and adopting 2.4G wireless signal transmission technology, with a control distance of up to 30 meters, is adopted. Compatible with 2.4 GHz wireless and wireless controller single color remote controls, the wireless controller LED dimmer will receive the signal from the remote control and transmit the signal to other same dimmers within 30 meters.
• wireless controller Single Color LED Dimmer Manual
• Size: 119*37.5*22mm(L*W*H)
• Transmitting Power: 6 dBm
• Output Connection: Common Anode
• 4G RF Remote Controllable
• Compatible With T2, T1, WL
• Supports Smart Phone APP And Third-Party Voice Control(Need 2. Gateway)

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Size: 119*37.5*22mm(L*W*H)
• Working Voltage: -24V
• Output Current: Max 12A
• Transmitting Power: 6 dBm
• Control Distance: 30m
• Output Connection: Common Anode
• Working Temperature: -20℃-+60℃
• LumaCircuit model: LC-CTL-DHFB89
• Dimensions found: 119x37.5x22mm / 22mm / 30m

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller LED dimmer controller is designed for single-color LED strips. Working on DC12V and DC24V, and adopting 2.4G wireless signal transmission technology, with a control distance of up to 30 meters, is adopted. Compatible with 2.4 GHz wireless and wireless controller single color remote controls, the wireless controller LED dimmer will receive the signal from the remote control and transmit the signal to other same dimmers within 30 meters. The installer can use the remote controls to adjust the brightness from 1% to 100%. After adding the 2.4G gateway WL. The installer can use the smartphone APP and third-party voice to control the LED lights, which supports Amazon Alexa and Google Assistant.

Quick Links

wireless controller Single Color LED Dimmer Manual

Specifications

Size: 119*37.5*22mm(L*W*H)

Working Voltage: -24V

Output Current: Max 12A

RF: 2.

Transmitting Power: 6 dBm

Control Distance: 30m

Output Connection: Common Anode

4G RF Remote Controllable

Compatible With T2, T1, WL

Supports Smart Phone APP And Third-Party Voice Control(Need 2. Gateway)

Signal Transmitting

Working Temperature: -20℃-+60℃

Includes

1 * wireless controller Single Color LED Dimmer Controller
