DL X 5 In 1 DALI LED Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller 5-In-1 DALI LED controller has 5 output modes and supports monochrome, color temperature, RGB, RGBW, and RGB+CCT LED lights. The DALI controller complies with DALI standard protocols and supports the type. It can work with the wireless controller touch panel remote to set the color and adjust color temperature, brightness, and saturation. There are 16 million colors available. The digital tube display will show you the information intuitively.
• wireless controller DALI Light Controller
• Size: 130*49*27mm(L*W*H)
• Input Signal: DALI Or Push Dimming
• DALI Bus Standard: -102, 207, 209
• Output Current: 6A/Channel
• Total Output Current: 20A
• 5 Output Modes: Monochrome, Color Temperature, RGB, RGBW, RGB+CCT

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: RGB+CCT
• Size: 130*49*27mm(L*W*H)
• Working Voltage: -24V
• Input Signal: DALI Or Push Dimming
• DALI Bus Standard: -102, 207, 209
• Output Current: 6A/Channel
• Total Output Current: 20A
• 5 Output Modes: Monochrome, Color Temperature, RGB, RGBW, RGB+CCT
• Working Temperature: -10-40℃
• LumaCircuit model: LC-CTL-LG2BF8
• Dimensions found: 130x49x27mm / 27mm

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller 5-In-1 DALI LED controller has 5 output modes and supports monochrome, color temperature, RGB, RGBW, and RGB+CCT LED lights. The DALI controller complies with DALI standard protocols and supports the type. It can work with the wireless controller touch panel remote to set the color and adjust color temperature, brightness, and saturation. There are 16 million colors available. The digital tube display will show you the information intuitively. There are 2 dimming curves available, and the installer can choose logarithmic and linear dimming. The wireless controller DALI RGB controller supports push dimming, and the brightness of the LED lights and the ON/OFF of the LED lamps can be controlled by the push button.

Quick Links

wireless controller DALI Light Controller

Specifications

Size: 130*49*27mm(L*W*H)

Working Voltage: -24V

Input Signal: DALI Or Push Dimming

DALI Bus Standard: -102, 207, 209

Output Current: 6A/Channel

Total Output Current: 20A

5 Output Modes: Monochrome, Color Temperature, RGB, RGBW, RGB+CCT

16 Million Colors Available

Adjust Color Temperature, Brightness, Saturation

2-Dimming Curves Optional: Logarithmic/Linear

With Digital Tube Display

Working Temperature: -10-40℃

Automatically Detect When Power On

Anti-Reverse Connection Protection

Short-Circuit Protection

Overcurrent Protection And Recovery Function

Includes

1 * wireless controller DALI Controller
