Mini Inline LED Dimmer 12V PWM With RF Remote Control
LumaCircuit offers Mini Inline LED Dimmer 12V PWM With RF Remote Control as a configurable LED controller for project builds. Typical applications include Serviceable strip wiring, Power injection, Cabinet and display installation. Connecting Method: Common Anode Static Power Consumption: <0.5W Power: <30W(DC5V), <72W(DC12V), <144W(DC24V) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The mini Inline LED dimmer 12V PWM, which has 5.5*2.1mm DC male and female connectors, is easy to connect to the single color LED lights and LED power supply, the remote control dimmer for LED lights with one output channel design and max output current is 6A, the 14 keys RF remote control included, the installer can use it to control the LED lights remotely, turn on/off, adjust the brightness from 0 to 100%, adjust the speed of dynamic modes, there are three dynamic modes available, Jump, Fade and Strobe.
- Connecting Method: Common Anode
- Static Power Consumption: <0.5W
- Power: <30W(DC5V), <72W(DC12V), <144W(DC24V)
- Working Temperature: -20℃-+60℃
- 14 Keys RF Remote Control Included
- Modes: Jump, Fade, Strobe
- Brightness And Speed Adjustable
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 5-24 V / 5 V / 24 V
- Colors: Black
- Size: 55*22*13mm(L*W*H)
- Working Voltage: -24V
- Static Power Consumption: <0.5W
- Output Channel: 1
- Max Output Current: 6A
- Power: <30W(DC5V), <72W(DC12V), <144W(DC24V)
- Working Temperature: -20℃-+60℃
- Modes: Jump, Fade, Strobe
- Remote Control Distance: ≤20M
- LumaCircuit model: LC-CTL-WCKMQ2
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Serviceable strip wiring, Power injection, Cabinet and display installation. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The mini Inline LED dimmer 12V PWM, which has 5.5*2.1mm DC male and female connectors, is easy to connect to the single color LED lights and LED power supply, the remote control dimmer for LED lights with one output channel design and max output current is 6A, the 14 keys RF remote control included, the installer can use it to control the LED lights remotely, turn on/off, adjust the brightness from 0 to 100%, adjust the speed of dynamic modes, there are three dynamic modes available, Jump, Fade and Strobe. The installer can use it to work with single-color LED flexible strips and conveniently control brightness.
Specifications
Colors: Black
Size: 55*22*13mm(L*W*H)
Working Voltage: -24V
Connecting Method: Common Anode
Static Power Consumption: <0.5W
Output Channel: 1
Max Output Current: 6A
Power: <30W(DC5V), <72W(DC12V), <144W(DC24V)
Working Temperature: -20℃-+60℃
14 Keys RF Remote Control Included
Modes: Jump, Fade, Strobe
Brightness And Speed Adjustable
The LED Dimmer With 5.5*2.1mm DC Connectors
Remote Control Distance: ≤20M
Includes
1 * Inline dimmer for LED lights
1 * 14 Keys RF Remote Control
Typical applications
- Serviceable strip wiring
- Power injection
- Cabinet and display installation
