DC24V 1 Channel Amplifier For Single Color LEDs
LumaCircuit offers DC24V 1 Channel Amplifier For Single Color LEDs as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Type: 1-Channel High-Performance Amplifier Size: 86.5*62.5*21.2mm(L*W*H) Connection: Common Anode The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller high-performance Amplifier has a one-channel output design, an excellent choice for powering single-color LED strips. Compatible with compatible 2.4 GHz wireless remotes series controllers and all PMW-type light controllers in the market. It adopts a high current MOSFET output to ensure high output power. It has a high-speed optical coupler and a 10 Mbps output rate. The wireless controller amplifier works on DC24V, and the maximum output current is 25A.
- Type: 1-Channel High-Performance Amplifier
- Size: 86.5*62.5*21.2mm(L*W*H)
- Connection: Common Anode
- IP Rate: IP20 Non-waterproof
- Working Temperature: -10-40℃
- 1 * One Channel Amplifier
- The wireless controller 1 Channel Amplifiers with high performance and high speed design, are an excellent choice for powering single-color LED Strips.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 24 V
- Size: 86.5*62.5*21.2mm(L*W*H)
- Color: Black
- Input Voltage: DC24V
- Max Output Current: 25A
- IP Rate: IP20 Non-waterproof
- Working Temperature: -10-40℃
- LumaCircuit model: LC-CTL-EE2AS2
- Dimensions found: 86.5x62.5x21.2mm / 21.2mm
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller high-performance Amplifier has a one-channel output design, an excellent choice for powering single-color LED strips. Compatible with compatible 2.4 GHz wireless remotes series controllers and all PMW-type light controllers in the market. It adopts a high current MOSFET output to ensure high output power. It has a high-speed optical coupler and a 10 Mbps output rate. The wireless controller amplifier works on DC24V, and the maximum output current is 25A. Its metal shell design is conducive to heat dissipation and safer to use.
Specifications
Type: 1-Channel High-Performance Amplifier
Size: 86.5*62.5*21.2mm(L*W*H)
Color: Black
Input Voltage: DC24V
Max Output Current: 25A
Switching Rate: 10 Mbps
Connection: Common Anode
IP Rate: IP20 Non-waterproof
Working Temperature: -10-40℃
Includes
1 * One Channel Amplifier
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
