5 In 1 Smart Light Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller LS smart light controller with 5 in 1 design and 5 output channels can be used for single color, CCT, RGB, RGBW, and RGB+CCT LED strips. There is a mode switch button on the LED controller, and the installer can press it to switch the working mode. Easy to choose static colors or dynamic modes. The saturation, brightness, and color temperature are adjustable for various scenes. The controller is compatible with most of wireless controller's 2 remote controls that control distances up to 30m.
• wireless controller Smart Controller Manual
• Size: 124*38*23mm(L*W*H)
• Output Current: Total 15A, 6A/Channel Max, 5 Output Channels
• Transmitting Power: 6 dBm
• Connection: Common Anode
• Compatible With Single Color, CCT, RGB, RGBW, RGB+CCT LED Light Strips
• Signal Transmitting & Mode Synchronization

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: RGB+CCT
• Size: 124*38*23mm(L*W*H)
• Working Voltage: -24V
• Output Current: Total 15A, 6A/Channel Max, 5 Output Channels
• Transmitting Power: 6 dBm
• Control Distance: 30m
• LumaCircuit model: LC-CTL-4A0YH8
• Dimensions found: 124x38x23mm / 23mm / 30m

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around Serviceable strip wiring, Power injection, Cabinet and display installation. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller LS smart light controller with 5 in 1 design and 5 output channels can be used for single color, CCT, RGB, RGBW, and RGB+CCT LED strips. There is a mode switch button on the LED controller, and the installer can press it to switch the working mode. Easy to choose static colors or dynamic modes. The saturation, brightness, and color temperature are adjustable for various scenes. The controller is compatible with most of wireless controller's 2 remote controls that control distances up to 30m. After adding the 2 gateway(WL ), the installer can use the smartphone APP control and third-party voice to control the LED lights. Supports Amazon Alexa and Google Assistant. The smart LED controller will receive the signal and transmit it to other controllers within 30M, and all FCOB LED light strips will work synchronously when they are started at different times, controlled by the same remote, under the same dynamic mode, and within 30m distance.

Quick Links

wireless controller Smart Controller Manual

Specifications

Size: 124*38*23mm(L*W*H)

Working Voltage: -24V

Output Current: Total 15A, 6A/Channel Max, 5 Output Channels

RF: 2.

Transmitting Power: 6 dBm

Control Distance: 30m

Connection: Common Anode

Compatible With Single Color, CCT, RGB, RGBW, RGB+CCT LED Light Strips

Signal Transmitting & Mode Synchronization

Remote & Smartphone Control

Supports Third-Party Voice Control

Compatible With T4, T3, T2, T1, WL

Switching Mode By One Button

6 Channel 5 Circuits Connector

Includes

1 * wireless controller Smart Light Controller
