RGBW Light Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller RGBW light controllers are designed for RGB and RGBW LED strips, work on DC12V and DC24V, with 5-port terminals, and are easy to connect to the LED light. The wireless controller RGBW controller with a 2.4G and RF module can remotely control the LED light via the remote control and the app.
• wireless controller RGBW Controller Manual
• Size: 119*37.5*22mm(L*W*H)
• Output Current: 6A/Channel
• Transmitting Power: 6 bBm
• Output Connection: Common Anode
• Remote Control & APP Control
• Supports Third-Party Voice Control

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: RGBW
• Size: 119*37.5*22mm(L*W*H)
• Working Voltage: -24V
• Output Current: 6A/Channel
• Total Output: 12A Max
• Transmitting Power: 6 bBm
• Control Distance: ≤30M
• Output Connection: Common Anode
• LumaCircuit model: LC-CTL-797EUO
• Dimensions found: 119x37.5x22mm / 22mm / 30M

Control and installation

Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.

Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller RGBW light controllers are designed for RGB and RGBW LED strips, work on DC12V and DC24V, with 5-port terminals, and are easy to connect to the LED light. The wireless controller RGBW controller with a 2.4G and RF module can remotely control the LED light via the remote control and the app. Compatible with most wireless controller 2.4G RF remote controls, the installer can add one 2.4G gateway to support smartphone APP control and third-party voice control, which can work with Amazon Alexa and Google Assistant. There are 16 million colors available, and the installer can adjust the static color's brightness or the dynamic mode's speed. The RGBW controller will receive the signal from the remote control and transmit it to the controllers within 30 meters. Different controllers will work synchronously.

Quick Links

wireless controller RGBW Controller Manual

Specifications

Size: 119*37.5*22mm(L*W*H)

Working Voltage: -24V

Output Current: 6A/Channel

Total Output: 12A Max

RF: 2.

Transmitting Power: 6 bBm

Control Distance: ≤30M

Output Connection: Common Anode

Remote Control & APP Control

Supports Third-Party Voice Control

16 Million Colors Available

Brightness And Saturation Adjustable

The Remote Control Sold Separately

Compatible With T4, T3, WL

Signal Transmitting

Modes Synchronization

Includes

1 * wireless controller RGBW Light Controller
