4Pin RGB Controller

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller 4Pin RGB controllers can control various RGB lighting products, LED strips, RGB wall washers, etc. The wireless remote control is included. This 4Pin controller adopts widely used wireless technology for low power consumption, longer signal transmission, strong anti-interference, etc. It works on DC12V or DC24V; the max output current is 12A. It is widely used to control hotel and home lighting.
• wireless controller User Manual
• Model: (RGB), (Single Color), (Dual White)
• Size: 119*37.5*22mm(L*W*H)
• Output: 6A/Channel(RGB), 12A/Channel(CCT, Single Color)
• Total Output Current: Max 12A
• Output Connection: Common Anode
• Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: CCT
• LumaCircuit model: LC-CTL-9ZMMCJ
• Size: 119*37.5*22mm(L*W*H)
• Working Voltage: -24V
• Output: 6A/Channel(RGB), 12A/Channel(CCT, Single Color)
• Total Output Current: Max 12A
• Control Distance: ≤30m
• Output Connection: Common Anode
• IP Rating: IP20 Non-Waterproof
• Working Temperature: -20-60℃
• Dimensions found: 119x37.5x22mm / 22mm / 30m

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller 4Pin RGB controllers can control various RGB lighting products, LED strips, RGB wall washers, etc. The wireless remote control is included. This 4Pin controller adopts widely used wireless technology for low power consumption, longer signal transmission, strong anti-interference, etc. It works on DC12V or DC24V; the max output current is 12A. It is widely used to control hotel and home lighting. The installer can use them to adjust the brightness of static color and the speed of dynamic mode. There are 16 million colors and 15 dynamic modes available. The installer can choose your favorite color or mode for various scenes.

Quick Links

wireless controller User Manual

4Pin RGB Controller Specifications

Model: (RGB), (Single Color), (Dual White)

Size: 119*37.5*22mm(L*W*H)

Working Voltage: -24V

Output: 6A/Channel(RGB), 12A/Channel(CCT, Single Color)

Total Output Current: Max 12A

RF

Control Distance: ≤30m

Output Connection: Common Anode

16 Million Colors Available

15 Dynamic Modes Available

Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable

IP Rating: IP20 Non-Waterproof

Working Temperature: -20-60℃

Remote Control Specifications

Size: 114*55.5*22mm(L*W*H)

Working Voltage: DC3V

Powered By 2PCS AAA Batteries(Sold Separately)

RF

Transmitting Power: <

Modulation Method: ASK

Control Distance: ≤30m

Working Temperature: -20-60℃

Includes

1 * 4Pin RGB Controller

1 * Wireless Remote Control

1 * User Manual
