4G RF 4Pin RGB Controller
LumaCircuit offers 4G RF 4Pin RGB Controller as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. wireless controller RGB Light Controller Manual Size: 119*37.5*22mm(L*W*H) Output Current: Max 6A/Channel The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller 4PIN RGB controller adopts 2.4G wireless signal transmission technology and a control distance of up to 30 meters. The RGB controller will receive the signal from the remote controls and transmit the signal to other controllers within 30m. Different controllers will work synchronously when they are started at various times. The wireless controller is compatible with 2.4 GHz wireless remote controls, and the installer can use the remote control to choose the color or set the dynamic mode.
- wireless controller RGB Light Controller Manual
- Size: 119*37.5*22mm(L*W*H)
- Output Current: Max 6A/Channel
- Transmitting Power: 6 dBm
- Output Connection: Common Anode
- Brightness And Saturation Adjustable
- Mix RGB To Adjust Color Temperature
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12-24 V
- Light engine: RGB
- Size: 119*37.5*22mm(L*W*H)
- Working Voltage: -24V
- Output Current: Max 6A/Channel
- Total Output Max: 12A
- Transmitting Power: 6 dBm
- Control Distance: ≤30m
- Output Connection: Common Anode
- Compatible 2.4 GHz wireless And wireless controller 2. RF Remote Controls: wireless controller T4, T3, WL
- Working Temperature: -20℃-+60℃
- LumaCircuit model: LC-CTL-T15MO9
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller 4PIN RGB controller adopts 2.4G wireless signal transmission technology and a control distance of up to 30 meters. The RGB controller will receive the signal from the remote controls and transmit the signal to other controllers within 30m. Different controllers will work synchronously when they are started at various times. The wireless controller is compatible with 2.4 GHz wireless remote controls, and the installer can use the remote control to choose the color or set the dynamic mode. There are 16 million colors available, and the brightness and saturation are adjustable. After adding the 2.4G gateway WL the Phone APP can control the wireless controller RGB controller and third-party voice support, Amazon Alexa, and Google Assistant.
Quick Links
wireless controller RGB Light Controller Manual
Specifications
Size: 119*37.5*22mm(L*W*H)
Working Voltage: -24V
Output Current: Max 6A/Channel
Total Output Max: 12A
RF: 2.
Transmitting Power: 6 dBm
Control Distance: ≤30m
Output Connection: Common Anode
16 Million Colors Available
Brightness And Saturation Adjustable
Mix RGB To Adjust Color Temperature
Compatible 2.4 GHz wireless And wireless controller 2. RF Remote Controls wireless controller T4, T3, WL
Support APP Control And Third-Party Voice Control(Need wireless controller WL- 2.4G Gateway)
Signal Transmitting
Modes Synchronization
Working Temperature: -20℃-+60℃
Includes
1 * 4Pin RGB Controller
