720W 12V RGB Controller With Touch Remote Control
LumaCircuit offers 720W 12V RGB Controller With Touch Remote Control as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Connecting Mode: Common Anode Output Current: <10A(Each Channel) Max Output Power: <360W(12V), 720W(24V) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The 12V RGB controller uses an advanced microcontroller to control a variety of RGB LED lights. The RGB controller is designed with three output channels. The max output current of each channel is 10A, and the max load power is 720W at DC24V. The RGB LED controller with dual cable ports allows multiple controllers to be connected to enable synchronization. All of the loading LED lights will change the lighting effects synchronously.
- Connecting Mode: Common Anode
- Output Current: <10A(Each Channel)
- Max Output Power: <360W(12V), 720W(24V)
- Output Gray: 256 Levels (RGB Each)
- RF Remote Control With 1 Color Ring, 1 Color Sense Lamp In The Center, All Buttons In The Touch Form
- Ports For Sync-Work Function
- 10 Working Modes In Total, Including 1 White Static Color And 9 Dynamic Modes
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 12-24 V / 24 V
- Light engine: RGB
- Size: 91*88*24mm(L*W*H)
- Connecting Mode: Common Anode
- Working Voltage: -24V
- Output Channels: 3
- Output Current: <10A(Each Channel)
- Max Output Power: <360W(12V), 720W(24V)
- RF Frequency: 433.
- Output Gray: 256 Levels (RGB Each)
- Working Temperature: -20℃-60℃
- LumaCircuit model: LC-CTL-15GFVQ
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The 12V RGB controller uses an advanced microcontroller to control a variety of RGB LED lights. The RGB controller is designed with three output channels. The max output current of each channel is 10A, and the max load power is 720W at DC24V. The RGB LED controller with dual cable ports allows multiple controllers to be connected to enable synchronization. All of the loading LED lights will change the lighting effects synchronously. The touch RF remote control includes one color ring and one color-sensing lamp in the center, and all buttons are tactile. The color ring has 128 levels in different colors. Ten models include the static white and nine dynamic modes; the static color's brightness and the dynamic mode's speed are adjustable.
Specifications
Size: 91*88*24mm(L*W*H)
Connecting Mode: Common Anode
Working Voltage: -24V
Output Channels: 3
Output Current: <10A(Each Channel)
Max Output Power: <360W(12V), 720W(24V)
RF Frequency: 433.
Output Gray: 256 Levels (RGB Each)
RF Remote Control With 1 Color Ring, 1 Color Sense Lamp In The Center, All Buttons In The Touch Form
Ports For Sync-Work Function
10 Working Modes In Total, Including 1 White Static Color And 9 Dynamic Modes
Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable
Weight: 320g
Working Temperature: -20℃-60℃
Includes
1 * 12V RGB Controller
1 * LED Touch Remote
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
