3 Channels RGB LED Light Amplifiers
LumaCircuit offers 3 Channels RGB LED Light Amplifiers as a configurable LED controller for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Type: 3-Channel LED Light Amplifier Working Temperature: -10-60℃ The RGB LED Light Amplifiers with 3 independent output channels, integrates ultra-power MOS output for high load capacity, can work with regular RGB LED Strip Lights. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The 3-channel RGB LED light amplifiers have ultra-power MOS output for high load capacity. They will receive, process, and transmit a high-frequency PMW signal from the RGB LED controllers of up to 30 KHz to achieve accurate light control. These amplifiers can help create stunning visual displays in various applications by providing additional LED power and control. The input voltage ranges from DC5V to DC24V, and the input and output voltage can differ.
- Type: 3-Channel LED Light Amplifier
- Working Temperature: -10-60℃
- The RGB LED Light Amplifiers with 3 independent output channels, integrates ultra-power MOS output for high load capacity, can work with regular RGB LED Strip Lights.
- A serviceable controller component for a complete lighting BOM.
- The configured light engine is RGB.
- The recorded electrical input is 5-24 V.
- Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 5-24 V
- Light engine: RGB
- LumaCircuit model: LC-CTL-M4WQAP
- Material: ABS
- Size: 98*42*20mm(L*W*H)
- Input Voltage: -24V
- Output: 6A Per Channel
- Total Output: 12A Max
- Working Temperature: -10-60℃
- Dimensions found: 98x42x20mm / 20mm
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The 3-channel RGB LED light amplifiers have ultra-power MOS output for high load capacity. They will receive, process, and transmit a high-frequency PMW signal from the RGB LED controllers of up to 30 KHz to achieve accurate light control. These amplifiers can help create stunning visual displays in various applications by providing additional LED power and control. The input voltage ranges from DC5V to DC24V, and the input and output voltage can differ. With 3 output channels designed, each channel can be used independently or combined. The installer can use them for the regular RGB color-changing COB and SMD LED strip lights.
Specifications
Type: 3-Channel LED Light Amplifier
Model
Material: ABS
Size: 98*42*20mm(L*W*H)
Input Voltage: -24V
Working Current
Output: 6A Per Channel
Total Output: 12A Max
Working Temperature: -10-60℃
Includes
1 * Amplifier
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
