4G RF RGB Controller With Touch Remote

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller RGB controller adopts the most advanced PWM control technology. The installer can use them to control the RGB LED strips and modules, working on DC12V or DC24V, the input side with screw ports and DC port, easy to connect to the LED adapter, the output side with four screw ports and three output channels, easy to connect to the RGB lighting strips.
• wireless controller RGB Controller Manual
• Output Channels: R/G/B 3 Output Channels
• Max Load Per Channel: 6A
• Output Connection: Common Anode
• Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable
• 4G Signal Wireless Transmission
• Fabrication Processing: Multicolor Printing & UV Varnish

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 12-24 V
• Light engine: RGB
• Size: 85*45*23mm(L*W*H)
• Working Voltage: -24V
• Output Channels: R/G/B 3 Output Channels
• Max Load Per Channel: 6A
• Total Output Max: 10A
• Output Connection: Common Anode
• Control Distance: ≤30m
• LumaCircuit model: LC-CTL-3J36PZ
• Material: ABS
• Dimensions found: 85x45x23mm / 23mm / 30m

Control and installation

Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.

Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller RGB controller adopts the most advanced PWM control technology. The installer can use them to control the RGB LED strips and modules, working on DC12V or DC24V, the input side with screw ports and DC port, easy to connect to the LED adapter, the output side with four screw ports and three output channels, easy to connect to the RGB lighting strips. The installer can use the remote to set 630 thousand colors and 20 dynamic working modes, and the brightness of static colors and speed of dynamic modes are adjustable. With the memory function, the previous settings will be resumed when power is on again. The wireless controller RGB controller and remote have 2.4G signal wireless transmission technology, a control distance of up to 30 meters. The RF remote has simple and practical functions such as changing color and dimming brightness. The capacitive touch screen design makes the remote easy to use.

Quick Links

wireless controller RGB Controller Manual

Product detail 02

Size: 85*45*23mm(L*W*H)

Working Voltage: -24V

Output Channels: R/G/B 3 Output Channels

Max Load Per Channel: 6A

Total Output Max: 10A

Output Connection: Common Anode

Control Distance: ≤30m

16 Million Colors And 20 Dynamic Working Modes Available

Brightness Of Static Colors And Speed Of Dynamic Modes Adjustable

Memory Function: YES

4G Signal Wireless Transmission

Touch Remote Specifications

Material: ABS

Fabrication Processing: Multicolor Printing & UV Varnish

Size: 110*52*20mm(L*W*H)

Working Voltage: DC3V

Powered By 2PCS AAA Batteries(Sold Separately)

Includes

1 * wireless controller RGB Controller

1 * Touch Remote

1 * User Manual
