Sync DC12V 24V CCT LED Controller
LumaCircuit offers Sync DC12V 24V CCT LED Controller as a configurable LED controller for project builds. Typical applications include CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Working Voltage: -20-60℃ Working Voltage: DC12V-DC24V Static Power Consumption: <1W The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The Sync DC12V-24V CCT LED controller can be paired with the touch wall panel remote control, designed for the CW+WW constant voltage LED lights to adjust the brightness or color temperature easily. It works on DC12V or DC24V, the CCT LED controller with two channels output, the max output current of each channel is 10A, and it adopts the advanced PWM digital control technology, which controls constant voltage tunable white LED strips.
- Working Voltage: -20-60℃
- Working Voltage: DC12V-DC24V
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Output Current: ≤10A(Each Channel)
- Max Output Power: 240W(DC12V)/480W(DC24V)
- Short Circuit Protection: YES
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 24 V
- Light engine: CCT
- Working Voltage: -20-60℃
- Size: * * mm
- Working Voltage: DC12V-DC24V
- Static Power Consumption: <1W
- Connecting Mode: Common Anode
- Output Channels: 2
- Output Current: ≤10A(Each Channel)
- Max Output Power: 240W(DC12V)/480W(DC24V)
- PWM Frequency: 433.
- Remote Distance: 20M
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The Sync DC12V-24V CCT LED controller can be paired with the touch wall panel remote control, designed for the CW+WW constant voltage LED lights to adjust the brightness or color temperature easily. It works on DC12V or DC24V, the CCT LED controller with two channels output, the max output current of each channel is 10A, and it adopts the advanced PWM digital control technology, which controls constant voltage tunable white LED strips. With 2 input ports and output with four interfaces, including two identical V+ for positive interfaces, the other two for the CW and WW control interface, with memory function, each time power-on, reserves the mode that was stopped in the last power off. You could adjust the brightness, color temperature and various dynamic changes in lighting effects through the touch wall panel remote control, the RF remote control with one dimming ring and five function buttons, control range up to the working voltage of the wall panel control between AC90V to AC265V, the structure/dimension/installation of the wall panel remote control according to the 86-type European standard, easy to install and use. Long-press the brightness and speed key to get fast adjustment. It's convenient to use the connectors to connect the multiple controllers together and achieve the synchronization function of thousands of meters of LED strips and other large quantities of LED lights; in theory, they can be connected in numerous ways.
CCT LED Controller Specifications
Working Voltage: -20-60℃
Size: * * mm
Working Voltage: DC12V-DC24V
Static Power Consumption: <1W
Connecting Mode: Common Anode
Output Channels: 2
Output Current: ≤10A(Each Channel)
Max Output Power: 240W(DC12V)/480W(DC24V)
PWM Frequency: 433.
Remote Distance: 20M
Gray Scale: 256 Levels
Speed Stage: 100 Grade
Memory Function: YES
Short Circuit Protection: YES
Weight: 360g
Touch Wall Panel Remote Specifications
Dimension: 86*86*34mm(lL*W*H)
Working Temperature: 0℃-45℃
Working Voltage: -265V(50/60Hz)
Standby Power: 0.2W
Working Power: 2W
RF Frequency: 433.
RF Distance: ≤20m
Structure: 86-Type European Standard
Weight: 130g
Includes
1 * CCT LED Controller
1 * Touch Wall Panel Remote Control
Typical applications
- CCT and RGB+CCT rooms
- Retrofit dimming
- Home Assistant lighting zones
