Product details
RGBWW 24W Low Voltage Wall Washer Lamps
LumaCircuit offers RGBWW 24W Low Voltage Wall Washer Lamps as a configurable linear LED light for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Type: Wall Washer RGBWW Lights Size: 994*36*27mm（L*W*H) Color Temperature Adjustable Range: 2700K(Warm White)-6500K(Cool White) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the WLED ambient route. Match the controller to the exact LED IC and channel order, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller 24W RGBWW wall washer lamps are a highly versatile lighting solution that can significantly enhance the ambiance and visual appeal of your exterior walls. The outdoor lighting system operates on low-voltage DC (24V to 48V), ensuring safety and energy efficiency while providing a wide and even distribution of light. The Wall Washing Lighting adopts high-quality LED lamp beads and excellent beam control to ensure uniform brightness.
- Type: Wall Washer RGBWW Lights
- Size: 994*36*27mm（L*W*H)
- Color Temperature Adjustable Range: 2700K(Warm White)-6500K(Cool White)
- Luminous Efficiency: 70LM/W
- Color Temperature Adjustable
- Communication Protocol: RF 2.
- 4G RF Remote Controllable T3, T4, WL
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 24-48 V
- Light engine: RGBW
- LumaCircuit model: LC-LIN-EKLKG9
- Size: 994*36*27mm（L*W*H)
- Input Voltage: -48V
- Power: 24W
- Color Temperature Adjustable Range: 2700K(Warm White)-6500K(Cool White)
- CRI: >
- Beam Angle: 24°
- Communication Protocol: RF 2.
- 2.4G RF Remote Controllable: T3, T4, WL
- Control Distance: ≤30M
Control and installation
Use this product on the WLED ambient route. Match the controller to the exact LED IC and channel order, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller 24W RGBWW wall washer lamps are a highly versatile lighting solution that can significantly enhance the ambiance and visual appeal of your exterior walls. The outdoor lighting system operates on low-voltage DC (24V to 48V), ensuring safety and energy efficiency while providing a wide and even distribution of light. The Wall Washing Lighting adopts high-quality LED lamp beads and excellent beam control to ensure uniform brightness. It integrates 2.4G wireless communication modules, allowing the wireless controller light to be controlled by an RF Remote to set the static color or dynamic mode. There are 16 million colors and 18 dynamic modes available. The installer can also adjust the color temperature, brightness, and saturation for various scenes. These wall light fixtures will receive signals from a remote control and transmit them to other lighting fixtures within a 30-meter range, enabling different lights to work in synchrony.
Specifications
Type: Wall Washer RGBWW Lights
Model
Size: 994*36*27mm（L*W*H)
Input Voltage: -48V
Power: 24W
16M Colors To Choose
Color Temperature Adjustable Range: 2700K(Warm White)-6500K(Cool White)
Luminous Flux: 1600LM
Luminous Efficiency: 70LM/W
Color Temperature Adjustable
Brightness Adjustable
Saturation Adjustable
CRI: >
Beam Angle: 24°
Communication Protocol: RF 2.
4G RF Remote Controllable T3, T4, WL
Control Distance: ≤30M
Illumination Distance: >15M
IP Rate: IP66
Working Temperature: -20-45℃
Includes
1 * 24W Wall Washer Lamp
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
