Product details
DC12V 2835 LED Module Light
LumaCircuit offers DC12V 2835 LED Module Light as a configurable LED module for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. The LED module light with PMMA lens, 160-degree angle view With a constant current driver, keep all LED modules at the same brightness Color: Warm White/Pure White/Cool White The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- New 2835 LED module light working in DC12V, use 2835 SMD LEDs as the light source
- The LED module light with PMMA lens, 160-degree angle view
- With a constant current driver, keep all LED modules at the same brightness
- Color: Warm White/Pure White/Cool White
- Color Rendering Index: 80
- Size: 82 mm*18 mm*7.3 mm
- 1 * 2835 LED Module Lights
- 2835 led module light, working in DC12V, use 2835 SMD LEDs as light source, with PMMA lens.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V
- Light engine: CCT
- LumaCircuit model: LC-MOD-LUF5WJ
- Color: Warm White/Pure White/Cool White
- LED: 2835 SMD LEDs
- LED Quantity: 3pcs
- Voltage: DC12V
- Power: 1.5W
- Lumen: 120lm
- Color Rendering Index: 80
- Size: 82 mm*18 mm*7.3 mm
- Beam angle: 160 degrees
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
New 2835 LED module light working in DC12V, use 2835 SMD LEDs as the light source
The LED module light with PMMA lens, 160-degree angle view
With a constant current driver, keep all LED modules at the same brightness
IP65 waterproof level
Specifications
LB-2835
Manufacturer
Color: Warm White/Pure White/Cool White
LED: 2835 SMD LEDs
LED Quantity: 3pcs
Voltage: DC12V
Power: 1.5W
IP Rating
Lumen: 120lm
Color Rendering Index: 80
Size: 82 mm*18 mm*7.3 mm
Beam angle: 160 degrees
1 * 2835 LED Module Lights
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
