Waterproof Injection 6 LED SMD Module With Lens
LumaCircuit offers Waterproof Injection 6 LED SMD Module With Lens as a configurable LED module for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Colors: Yellow, Pink, Green, Red, Blue, Cool White(7000-13000K), Warm White(2700-3200K) Luminous Flux: 40-70lm/PC IP Rating: IP65 Waterproof The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The SMD modules with optical lens, which uses 6PCS high-quality and super bright 5730 SMD LEDs as the light source, the LEDs mounted on the aluminum board and sealed in the PVC shell, the PVC shell made of the molding injection process, looks fashionable and high-temperature resistance and corrosion resistance, the IP rating is IP65 waterproof, can be used for the indoor and outdoor projects, the surface on the LEDs with optical lens, which for the wide beam angle.
- Colors: Yellow, Pink, Green, Red, Blue, Cool White(7000-13000K), Warm White(2700-3200K)
- Luminous Flux: 40-70lm/PC
- IP Rating: IP65 Waterproof
- With Optical Lens For Wide Angle View
- Back With Double-sided Adhesive Tape
- Cuttable And Reconnectable
- Working Temperature: -20°-+60°
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V
- Light engine: CCT
- LumaCircuit model: LC-MOD-64BJKX
- Size: 67*42*7mm(L*W*H)
- Material: PVC + ABS
- LED: 5730 SMD LEDs
- LED QTY: 6PCS/PC
- Working Voltage: DC12V
- Power: 3W
- Colors: Yellow, Pink, Green, Red, Blue, Cool White(7000-13000K), Warm White(2700-3200K)
- IP Rating: IP65 Waterproof
- Beam Angle: 120°
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The SMD modules with optical lens, which uses 6PCS high-quality and super bright 5730 SMD LEDs as the light source, the LEDs mounted on the aluminum board and sealed in the PVC shell, the PVC shell made of the molding injection process, looks fashionable and high-temperature resistance and corrosion resistance, the IP rating is IP65 waterproof, can be used for the indoor and outdoor projects, the surface on the LEDs with optical lens, which for the wide beam angle. 20PCS per string, cuttable and reconnectable, the installer can cut to any quantity and reconnect for your lighting project. The back has double-sided adhesive tape, so removing the protective paper from the tape and sticking it where you want to install it is easy. The center with a screw hole, the installer can use the screws to fix them on the surface of the lighting projects. Various emitting colors are available: cool white, warm white, red, blue, green, yellow, and pink, working in DC12V, easy to connect to the LED power supply to light up or connect to the LED lighting dimmer to adjust the brightness freely. The installer can use them as the backlight for the signs, billboards, channel letters, holiday decorations, reading lights for the cars, trucks, vans, etc.
Specifications
Model
Size: 67*42*7mm(L*W*H)
Material: PVC + ABS
LED: 5730 SMD LEDs
LED QTY: 6PCS/PC
Working Voltage: DC12V
Power: 3W
Colors: Yellow, Pink, Green, Red, Blue, Cool White(7000-13000K), Warm White(2700-3200K)
Luminous Flux: 40-70lm/PC
IP Rating: IP65 Waterproof
Beam Angle: 120°
With Optical Lens For Wide Angle View
Back With Double-sided Adhesive Tape
Cuttable And Reconnectable
With Screw Hole
Working Temperature: -20°-+60°
Includes
1 * SMD Module(20PCS/String)
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
