8*8/16*18/8*32 WS2812B Programmable LED Matrix Panel Screen
LumaCircuit offers 8*8/16*18/8*32 WS2812B Programmable LED Matrix Panel Screen as a configurable LED module for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Size: 8*8CM, 16*16CM, 8*32CM IC Type: WS2812B Built-in Compatible With Arduino And Other SD Programmable LED Controllers The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the WLED ambient route. Match the controller to the listed WS2812B LED type, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The programmable LED matrix panel screen has 3 sizes available. The installer can choose the various sizes with different SMD LEDs. The LEDs are mounted on the FPCB, and every piece of LED is built with a WS2812B IC. The LEDs can be controlled individually, working in DC5V, with Arduino controllers or other programmable SD controllers, arbitrarily cut off, flexible, easy to install, and bent.
- Size: 8*8CM, 16*16CM, 8*32CM
- IC Type: WS2812B Built-in
- Compatible With Arduino And Other SD Programmable LED Controllers
- Connections: VCC: Red; GND: Black; DAT: Blue
- 1 * Programmable LED Matrix Panel Screen
- The Programmable LED Matrix Panel Screen, 3 sizes available, the LEDs can be arbitrarily cut-off, flexible, easy to install and can be bending, can use them to achieve many amazing lighting effects like curtain-up, flow water, raindrop, etc.
- A production-ready panel family with a replaceable Zigbee control path.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 5 V
- Light engine: Addressable
- WLED chip: WS2812B
- Working Voltage: DC5V
- Power: 0.3W±0.01%/Pixel
- Size: 8*8CM, 16*16CM, 8*32CM
- LED: 5050 RGB SMD LEDs
- LED Chip: Epistar
- Beam Angle: 180°
- IP Rating: IP20
- LumaCircuit model: LC-MOD-DCWFDQ
- Dimensions found: 8x8CM / 16x16CM / 8x32CM / 8x8 / 16x18 / 8x32
Control and installation
Use this product on the WLED ambient route. Match the controller to the listed WS2812B LED type, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The programmable LED matrix panel screen has 3 sizes available. The installer can choose the various sizes with different SMD LEDs. The LEDs are mounted on the FPCB, and every piece of LED is built with a WS2812B IC. The LEDs can be controlled individually, working in DC5V, with Arduino controllers or other programmable SD controllers, arbitrarily cut off, flexible, easy to install, and bent. The installer can use them to achieve many amazing lighting effects like curtain-up, flowing water, raindrops, and jump flash. The installer can edit animation effects using CorelDRAW/Flash/lighting editor software. The IP rating is IP20 non-waterproof and only recommended for indoor or dry locations. The installer can use them in LED screens, walls, advertising boards, and other lighting projects.
Specifications
Working Voltage: DC5V
Power: 0.3W±0.01%/Pixel
Size: 8*8CM, 16*16CM, 8*32CM
LED: 5050 RGB SMD LEDs
LED Chip: Epistar
IC Type: WS2812B Built-in
Grayscale Levels: 256
Beam Angle: 180°
IP Rating: IP20
Compatible With Arduino And Other SD Programmable LED Controllers
Connections: VCC: Red; GND: Black; DAT: Blue
Includes
1 * Programmable LED Matrix Panel Screen
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
