Product details
Injection Waterproof 5050 LED Module 20PCS/String
LumaCircuit offers Injection Waterproof 5050 LED Module 20PCS/String as a configurable LED module for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Working Temperature: -25°-+60° Color: Red/Yellow/Blue/Green/Cool White/Warm White/RGB Color Temperature: Warm White(2700K-3200K), Cool White(9000-12000K), Red(620-625nm), Green(515-525nm), Blue(465-475nm), Yellow(585-595nm) The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The 5050 LED Modules use 4PCS high-quality and super-bright SMD LEDs as the light source. The LEDs are mounted on the aluminum board for better heat dissipation, with a fireproof ABS shell and epoxy sealed. The IP rating reaches IP65 for indoor and outdoor applications. The back has double side adhesive tape and both sides with screw holes, take off the protector on the tape and stick on the place you want to install, or use the screws to fix them on the project.
- Working Temperature: -25°-+60°
- Color: Red/Yellow/Blue/Green/Cool White/Warm White/RGB
- Color Temperature: Warm White(2700K-3200K), Cool White(9000-12000K), Red(620-625nm), Green(515-525nm), Blue(465-475nm), Yellow(585-595nm)
- Luminous Flux/PC: White(80-88lm), Red(26lm), Green(50lm), Blue(16lm), Yellow(20lm)
- Color Rendering Index: >
- Back With Double-sided Adhesive Tape
- Both Sides With Screw Holes
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V
- Light engine: CCT
- LumaCircuit model: LC-MOD-F7IIP8
- Working Temperature: -25°-+60°
- Size: 55*33mm(L*W)
- LED: 5050 SMD LEDs
- LED Quantity: 4PCS
- Voltage: DC12V
- Power: 0.96W/PC
- IP Rating: IP65
- Lumen: 15-17lm/LED
- MCD/LED: 1300-1500
Control and installation
Pair this shared BOM component with the matched driver, wiring, mounting hardware and controller for the installation. The control boundary for this product is Matched driver, wiring or controller in the system BOM.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The 5050 LED Modules use 4PCS high-quality and super-bright SMD LEDs as the light source. The LEDs are mounted on the aluminum board for better heat dissipation, with a fireproof ABS shell and epoxy sealed. The IP rating reaches IP65 for indoor and outdoor applications. The back has double side adhesive tape and both sides with screw holes, take off the protector on the tape and stick on the place you want to install, or use the screws to fix them on the project. The 5050 LED modules, which have 20 pieces per string, are cuttable and reconnectable, and can be cut to any quantity and reconnected for your project. Working in DC12V, easy to connect to the LED adaptor to light up or connect the LED dimming controller to adjust the brightness for single color or color-changing style for the RGB. The installer can use them as the backlight for signs, channel letters, billboards, interior light for cars, trucks, vans, etc.
Specifications
Manufacturer: TYoung
Working Temperature: -25°-+60°
Size: 55*33mm(L*W)
LED: 5050 SMD LEDs
LED Quantity: 4PCS
Voltage: DC12V
Power: 0.96W/PC
IP Rating: IP65
Lumen: 15-17lm/LED
MCD/LED: 1300-1500
Power Factor: >0.9
Luminous Flux: 56-64lm
Color: Red/Yellow/Blue/Green/Cool White/Warm White/RGB
Color Temperature: Warm White(2700K-3200K), Cool White(9000-12000K), Red(620-625nm), Green(515-525nm), Blue(465-475nm), Yellow(585-595nm)
Luminous Flux/PC: White(80-88lm), Red(26lm), Green(50lm), Blue(16lm), Yellow(20lm)
Beam Angle: 120°
Color Rendering Index: >
20PCS Per String
Back With Double-sided Adhesive Tape
Both Sides With Screw Holes
Weight: 220g
1 * mold injection 5050 LED modules(20PCS/String)
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
