SYS 5W RGBWW In Ground Lights Outdoor

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The wireless controller 5W RGBWW in-ground outdoor lights is an excellent option for adding ambient lighting to your outdoor space. It must work with wireless controller 1-Channel Host Controller to fulfill the wireless remote control. There are 16 million colors available, and the installer can adjust the color temperature from 2700K to 6500K, brightness, and saturation for various scenes.
• wireless controller 1 Channel Host Controller
• wireless controller 1-Channel Signal Amplifier
• wireless controller User Manual
• Material: Aluminum + Stalinite
• Emitting Colors: RGB + CCT
• Color Temperature: 2700 K- 6500 K
• Light Efficiency: 70LM/W

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 24 V
• Light engine: RGB+CCT
• Material: Aluminum + Stalinite
• LumaCircuit model: LC-STR-NMB0LE
• Size: 100*74mm(W*H)
• Input Voltage: DC24V
• Power: 5W
• Emitting Colors: RGB + CCT
• Color Temperature: 2700 K- 6500 K
• CRI: >
• Beam Angle: 30°
• IP Rate: IP68 Waterproof

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The wireless controller 5W RGBWW in-ground outdoor lights is an excellent option for adding ambient lighting to your outdoor space. It must work with wireless controller 1-Channel Host Controller to fulfill the wireless remote control. There are 16 million colors available, and the installer can adjust the color temperature from 2700K to 6500K, brightness, and saturation for various scenes. The In-Ground Light uses high-lumen LED Chips as the light source, with a salinity mask and PC body for high hardness, nonbreakable, and high light transmittance. The surface has a stainless steel surface ring and silicone rubber sealing, ensuring excellent waterproofing and levels reach IP68. The installer can install them in a wet, damp, or wet location. If you want to add more in-ground LED lights for your project, the installer can add the SYS-T2 1-Channel signal amplifier to let all LED Lights work synchronously.

Quick Links

wireless controller 1 Channel Host Controller

wireless controller 1-Channel Signal Amplifier

wireless controller User Manual

Specifications

Material: Aluminum + Stalinite

Model

Size: 100*74mm(W*H)

Input Voltage: DC24V

Power: 5W

Emitting Colors: RGB + CCT

Color Temperature: 2700 K- 6500 K

Luminous Flux: 350lm

Light Efficiency: 70LM/W

16 Million Colors Available

9 Dynamic Modes Available

Color Temperature, Brightness, And Saturation Adjustable

Need To Work With wireless controller 1 Channel Host Controller

CRI: >

Beam Angle: 30°

IP Rate: IP68 Waterproof

Stainless Steel Surface Ring

High Lumen LED Chips

Stalinite Mask

Pressure And Corrosion Resistance PC Body

suited to Deck, Driveway, Stairs, Garden, Spot, Pathway, And Yard Decoration

Working Temperature: -20℃-+60℃

Includes

1 * wireless controller Outdoor In-Ground Light
