Product details
7/4MM 12V Battery Powered Small LED Strip Lights
LumaCircuit offers 7/4MM 12V Battery Powered Small LED Strip Lights as a configurable LED strip for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Type: Small LED Strip Lights Model: 2.7mm/4mm-SMD-12V LED Quantity: 198 LEDs/Meter The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The 12V battery-powered small LED strip lights are 2.7mm or 4mm wide, which allows them to be installed easily and add soft, ambient lighting in a small or limited space. They use the small 2016 SMD LEDs as the light source; each meter has 198 LEDs. Three emitting color products are available: 3000K warm white, 4000K natural white, and 6500K cool white. The back has double-sided adhesive tape, which makes it easy to stick on the surface where you want to install it.
- Type: Small LED Strip Lights
- Model: 2.7mm/4mm-SMD-12V
- LED Quantity: 198 LEDs/Meter
- Working Voltage: DC3V/DC5V/DC12V
- Colors: 3000K Warm White, 4000K Natural White, 6500K Cool White
- Luminous Flux: 160LM/LED
- Color Rendering Index: >
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 5 V
- Light engine: CCT
- LumaCircuit model: LC-STR-QIPD0Y
- Length: Roll
- Width: 2.7mm/4mm
- LED Type: 2016 SMD LEDs
- LED Quantity: 198 LEDs/Meter
- Working Voltage: DC3V/DC5V/DC12V
- Power: 5W
- Colors: 3000K Warm White, 4000K Natural White, 6500K Cool White
- Color Rendering Index: >
- Minimum Cutting Length: 10mm
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The 12V battery-powered small LED strip lights are 2.7mm or 4mm wide, which allows them to be installed easily and add soft, ambient lighting in a small or limited space. They use the small 2016 SMD LEDs as the light source; each meter has 198 LEDs. Three emitting color products are available: 3000K warm white, 4000K natural white, and 6500K cool white. The back has double-sided adhesive tape, which makes it easy to stick on the surface where you want to install it. The small-width LED strips are cuttable; the minimum cutting length is 10mm, and the installer can cut to any size for your project. Because of the low power consumption, the 12V super-narrow LED stripes can be powered by batteries, power banks, and UPS. They can work with WiFi smart light dimmers to adjust the brightness for various scenes suited to accent lighting or creating a cozy atmosphere in cars, cabinets, bedrooms, walls, etc. These Strip Lights are versatile and can be used in various settings.
Specifications
Type: Small LED Strip Lights
Model: 2.7mm/4mm-SMD-12V
Length: Roll
Width: 2.7mm/4mm
LED Type: 2016 SMD LEDs
LED Quantity: 198 LEDs/Meter
Working Voltage: DC3V/DC5V/DC12V
Power: 5W
Colors: 3000K Warm White, 4000K Natural White, 6500K Cool White
Luminous Flux: 160LM/LED
Color Rendering Index: >
Dimmable: YES
Minimum Cutting Length: 10mm
Beam Angle: 120°
Waterproof Level: IP20 Non-waterproof
Includes
1 * Battery Small LED Strip Light(5M/Roll)
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
