LED Strip Mini Amplifier DC12V 72W
LumaCircuit offers LED Strip Mini Amplifier DC12V 72W as a configurable LED strip for project builds. Typical applications include Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Item Type: Mini LED Amplifier Working temperature: -20 ℃-60 ℃ Voltage: DC5V, DC12V, DC24V The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the WLED ambient route. Match the controller to the exact LED IC and channel order, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The mini LED amplifier can work with 3528 RGB LED strips and 5050 color-changing flexible LED strips. It can work in DC12V, DC5V, and DC24V; the default is DC12V. It outputs 3 channels, and the current of each channel is 2 amps. When working in DC12V, it can support 5 meters of 5050 RGB LED strips or 15 meters of 3528 RGB LED strips. The side with the female DC connector connects with the LED power supply and the LED controller, and the other side connects with the LED strips, making it easy to install and use.
- Item Type: Mini LED Amplifier
- Working temperature: -20 ℃-60 ℃
- Voltage: DC5V, DC12V, DC24V
- Connecting mode: common anode
- Static power consumption: < 1W
- Power: 30w(DC5V), 72w(DC12V), 144w(DC24V)
- A serviceable controller component for a complete lighting BOM.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 5 V / 24 V
- Light engine: RGB
- LumaCircuit model: LC-STR-462O4Q
- Working temperature: -20 ℃-60 ℃
- Voltage: DC5V, DC12V, DC24V
- Output: 2A*3 Channels
- Connecting mode: common anode
- Static power consumption: < 1W
- Power: 30w(DC5V), 72w(DC12V), 144w(DC24V)
- Current: 2A per channel
Control and installation
Use this product on the WLED ambient route. Match the controller to the exact LED IC and channel order, voltage, data direction and total load; long runs also need a fuse and power-injection plan. WLED, Home Assistant and any show-control bridge remain separate validation points.
Plan the installation around Lighting system BOMs, OEM and ODM configurations, Replacement and service parts. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The mini LED amplifier can work with 3528 RGB LED strips and 5050 color-changing flexible LED strips. It can work in DC12V, DC5V, and DC24V; the default is DC12V. It outputs 3 channels, and the current of each channel is 2 amps. When working in DC12V, it can support 5 meters of 5050 RGB LED strips or 15 meters of 3528 RGB LED strips. The side with the female DC connector connects with the LED power supply and the LED controller, and the other side connects with the LED strips, making it easy to install and use.
Specifications
Manufacturer
Item Type: Mini LED Amplifier
Working temperature: -20 ℃-60 ℃
Voltage: DC5V, DC12V, DC24V
Output: 2A*3 Channels
Connecting mode: common anode
Dimension: **
Weight: 50g
Static power consumption: < 1W
Power: 30w(DC5V), 72w(DC12V), 144w(DC24V)
Current: 2A per channel
1 * Mini LED Amplifier
Typical applications
- Lighting system BOMs
- OEM and ODM configurations
- Replacement and service parts
