DC12V DC24V 5730 SMD Injection LED Modul
LumaCircuit offers DC12V DC24V 5730 SMD Injection LED Modul as a configurable LED strip for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Colors: Cool White, Warm White, Red, Yellow, Green, Blue LED Type: High Bright 5730 SMD LEDs Luminous Flux: 60-72LM/PC The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- Working Voltage: DC12V Or DC24V(Optional)
- Colors: Cool White, Warm White, Red, Yellow, Green, Blue
- LED Type: High Bright 5730 SMD LEDs
- Luminous Flux: 60-72LM/PC
- Max Connection Quantity: 25- 50PCS
- 20PCS Per Group, Price For One Piece Only
- Back With Double-sided Adhesive Tape
- Cuttable And Reconnectable
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 24 V
- Light engine: CCT
- LumaCircuit model: LC-STR-OX0QD4
- Working Voltage: DC12V Or DC24V(Optional)
- Size: 64*15*5mm
- Colors: Cool White, Warm White, Red, Yellow, Green, Blue
- Power: 1.5W
- LED Type: High Bright 5730 SMD LEDs
- LED Quantity: 6PCS
- Wire Length: 10cm
- IP Rating: IP65
- Applications: Indoor And Outdoor Applications
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Specifications
Model
Working Voltage: DC12V Or DC24V(Optional)
Size: 64*15*5mm
Colors: Cool White, Warm White, Red, Yellow, Green, Blue
Power: 1.5W
LED Type: High Bright 5730 SMD LEDs
LED Quantity: 6PCS
Luminous Flux: 60-72LM/PC
Max Connection Quantity: 25- 50PCS
Wire Length: 10cm
IP Rating: IP65
View Angle: 160°
20PCS Per Group, Price For One Piece Only
Back With Double-sided Adhesive Tape
Cuttable And Reconnectable
Applications: Indoor And Outdoor Applications
Working Temperature: -20℃-60℃
Includes
1 * 5730 SMD Injection LED Module
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
