Super Bright White LED Strip Lights 336LEDs/M Dual Row 24V

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The super bright white LED strip Lights can enhance the brightness and allow for a more even light distribution. The luminous flux is up to 2800lm per meter, especially for places you need to illuminate a large area or highlight specific features. The white LED strips use high-quality 2835 SMD LEDs as the light source and are in a dual-row configuration.
• Model: SMD-2835-336-DR-24V
• Size: 5000*10*2mm(L*W*H)
• Colors: 2700K (Warm White), 3000K (Warm White), 4000K (Natural White), 6500K (Cool White)
• Luminous Flux: 2700- 3000LM/Meter
• Luminous Efficiency: 24-26 LM/LED
• Minimum Cutting Length: 1.8cm
• Length: 5 Meters/Roll(16.4FT)

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 24 V
• Light engine: CCT
• LumaCircuit model: LC-STR-07RJTH
• Size: 5000*10*2mm(L*W*H)
• LED Type: 2835 SMD LEDs
• LED Quantity: 336 PCS/M
• Working Voltage: DC24V
• Power: 28W/M
• Colors: 2700K (Warm White), 3000K (Warm White), 4000K (Natural White), 6500K (Cool White)
• Color Index: >
• Minimum Cutting Length: 1.8cm
• Length: 5 Meters/Roll(16.4FT)

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The super bright white LED strip Lights can enhance the brightness and allow for a more even light distribution. The luminous flux is up to 2800lm per meter, especially for places you need to illuminate a large area or highlight specific features. The white LED strips use high-quality 2835 SMD LEDs as the light source and are in a dual-row configuration. The white LED tapes work at 24V, and the higher voltage allows for longer runs without experiencing voltage drop, ensuring consistent lighting performance throughout your installation. They come with an adhesive backing, allowing quick and secure mounting on various surfaces. For better heat dissipation, the reference recommends working with aluminum LED channels. Both ends have silicone-coated wires for high-temperature resistance; no need to worry about them melting. The super bright LED tapes are versatile and can be used for a wide range of applications, and the installer can use them in offices, museums, hotels, shops, exhibitions, etc.

Specifications

Model: SMD-2835-336-DR-24V

Size: 5000*10*2mm(L*W*H)

LED Type: 2835 SMD LEDs

LED Quantity: 336 PCS/M

Working Voltage: DC24V

Power: 28W/M

Colors: 2700K (Warm White), 3000K (Warm White), 4000K (Natural White), 6500K (Cool White)

Luminous Flux: 2700- 3000LM/Meter

Luminous Efficiency: 24-26 LM/LED

Color Index: >

Dimmable: YES

Minimum Cutting Length: 1.8cm

Length: 5 Meters/Roll(16.4FT)

Back With Double-sided Adhesive Tape

IP Ranking: IP33

Both Ends With Silicone wires

Applications: Cove Lighting, Bias Lighting, Task Lighting, Off-Grid Lighting, Photography Lighting, etc

Includes

1 * Super Bright White LED Strips(16.4FT)
