Product details
18W RGB CCT Outdoor Ground Lights
LumaCircuit offers 18W RGB CCT Outdoor Ground Lights as a configurable LED strip for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. wireless controller User Manual Input Voltage: -240V, 50/60Hz Emitting Color: RGB + CCT The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller Outdoor ground lights are versatile, energy-efficient LED lights designed for outdoor use. These lights feature a variety of lighting modes, including color-changing, dimmable, and static colors. The adjustable CCT range allows you to adjust the light to your desired color temperature, and the RGB technology enables you to create a range of colorful lighting effects.
- wireless controller User Manual
- Input Voltage: -240V, 50/60Hz
- Emitting Color: RGB + CCT
- Color Temperature: 2700 K- 6500 K
- Luminous Efficiency: 85LM/W
- Compatible With 2.4G Remote Controls wireless controller T4, WL
- Support Smartphone APP And Third-Party Voice Control: Amazon Alexa And Google Assistant(2.4G Gateway Needed)
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: RGB+CCT
- Size: 150*104.5mm(W*H)
- Color: Black
- Input Voltage: -240V, 50/60Hz
- Power: 18W
- Rated Current: 0.35A
- Emitting Color: RGB + CCT
- Color Temperature: 2700 K- 6500 K
- CRI: >80
- IP Rate: IP66
- Beam Angle: 25°
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller Outdoor ground lights are versatile, energy-efficient LED lights designed for outdoor use. These lights feature a variety of lighting modes, including color-changing, dimmable, and static colors. The adjustable CCT range allows you to adjust the light to your desired color temperature, and the RGB technology enables you to create a range of colorful lighting effects. The lights are waterproof and dustproof, and the waterproof level is IP66; the installer can use them for outdoor landscape lighting projects even in rainy conditions. The smart ground lights use high-lumen LED chips as a light source for a high color rendering index, highly restoring the color of objects. The surface has an anti-dazzling optical lens that will deliver scientifically symmetrical and bright light rays. 2.4 G RF remote controls can control the wireless controller outdoor lights. After pairing with a 2.4G gateway, controlled by a smartphone APP and third-party voice commands, the installer can set the color and conveniently adjust the brightness, saturation, and temperature for various scenes. One lamp will receive the remote control signals and transmit them to other same-model lamps within 30 meters. All of them will work synchronously.
Quick Links
wireless controller User Manual
Specifications
Size: 150*104.5mm(W*H)
Color: Black
Input Voltage: -240V, 50/60Hz
Power: 18W
Rated Current: 0.35A
Emitting Color: RGB + CCT
Color Temperature: 2700 K- 6500 K
Luminous Flux: 1500LM
Luminous Efficiency: 85LM/W
IP Rate: IP66
Beam Angle: 25°
RF: 2.
Compatible With 2.4G Remote Controls wireless controller T4, WL
Support Smartphone APP And Third-Party Voice Control: Amazon Alexa And Google Assistant(2.4G Gateway Needed)
Control Distance: ≤30m
Auto-Signal Transmitting And Auto-Mode Synchronization
Anti-Corrosion Inserted Pole Included
Working Temperature: -20-45℃
Includes
1 * 18W Outdoor Ground Light
1 * Anti-Corrosion Inserted Pole
1 * User Manual
Product resources
Technical documents
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
