DC5V 8MM FCOB LED Light Strips For Room Battery Powered

Product features

The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.

• The LED light strips are battery-powered for rooms, working on DC5V, and the installer can cut them to any size and light them up with batteries. The back has double-sided adhesive tape and is easy to install and use. The FCOB room LED light strips use Epistar LED chips as the light source, 320 PCS or 528 PCS per meter, 5 meters per reel, and a width of only 8mm; the installer can install them in a narrow location or the furniture.
• LED QTY: 320 LEDs/M, 528 LEDs/M
• Emitting Colors: Warm White(2700K), Warm White(3000K), Natural White(4000K), Cool White(6500K)
• IP Rating: IP20 Non-waterproof
• The Back With Double-Sided Adhesive Tape
• New COB LED Technology Produces Seamless Linear Light
• High-Density Design With 320PCS/528PCS LEDs Per Meter
• Lowest Profile Strip Solution For Light Without Visible Dots

Configuration and technical detail

To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.

• Input: 5 V
• Light engine: CCT
• Working Voltage: DC5V
• LED Chip: Epistar
• LED QTY: 320 LEDs/M, 528 LEDs/M
• Length: 5 Meters/Reel
• Width: 8mm
• Emitting Colors: Warm White(2700K), Warm White(3000K), Natural White(4000K), Cool White(6500K)
• Power: 5W/M
• IP Rating: IP20 Non-waterproof
• CRI: ≥
• LumaCircuit model: LC-STR-GMDJDJ

Control and installation

Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.

Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.

Configuration support

Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.

Product overview

The LED light strips are battery-powered for rooms, working on DC5V, and the installer can cut them to any size and light them up with batteries. The back has double-sided adhesive tape and is easy to install and use. The FCOB room LED light strips use Epistar LED chips as the light source, 320 PCS or 528 PCS per meter, 5 meters per reel, and a width of only 8mm; the installer can install them in a narrow location or the furniture. There are 3 colors available: warm white, natural white, and cool white, and the installer can choose your favorite color for your home or holiday decoration. The lowest working voltage is safe for children and pets. The IP rating is IP20 non-waterproof and only recommended for dry location installation. The installer can cut to any size and follow the cuttable marks for your project. The new COB LED technology will produce seamless linear light, with no diffused cover needed, and will not show visible dots or hot spots.

Specifications

Working Voltage: DC5V

LED Chip: Epistar

LED QTY: 320 LEDs/M, 528 LEDs/M

Length: 5 Meters/Reel

Width: 8mm

Emitting Colors: Warm White(2700K), Warm White(3000K), Natural White(4000K), Cool White(6500K)

Power: 5W/M

IP Rating: IP20 Non-waterproof

CRI: ≥

The Back With Double-Sided Adhesive Tape

Cuttable: YES

Dimmable: YES

View Angle: 120°

New COB LED Technology Produces Seamless Linear Light

High-Density Design With 320PCS/528PCS LEDs Per Meter

Lowest Profile Strip Solution For Light Without Visible Dots

Includes

1 * FCOB Bedroom LED Light Strips In Room(Reel）
