Product details
DC24V White Waterproof LED Wall Washer Light Strips
LumaCircuit offers DC24V White Waterproof LED Wall Washer Light Strips as a configurable LED strip for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Colors: Warm White(3000K), Natural White(4000K), Cool White(6500K) Beam Angle: 30°，45°，60°，20°45° Luminous Efficacy(LM/W): 116 The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The waterproof LED wall washer light strips can replace the traditional wall washer lights, with a small size and lightweight, easy to install, and light up. Landscape applications can be installed in wet, damp, or water locations. The wall light strips work in DC24V for a higher safety factor, use high-quality Epistar SMD LEDs as the light source, and have 48 LEDs per meter.
- Colors: Warm White(3000K), Natural White(4000K), Cool White(6500K)
- Beam Angle: 30°，45°，60°，20°45°
- Luminous Efficacy(LM/W): 116
- Working Temperature: -25℃-+45℃
- 1 * White Waterproof LED Wall Washer Light Strips
- The White Waterproof LED Wall Washer Light Strips, can replace the traditional Wall Washer Lights, various beam angle products available, the installer can install them in a wet, damp or water location for landscape applications.
- A production-ready linear family with a replaceable Zigbee control path.
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 24 V
- Light engine: CCT
- Size: 18.5*9.5mm(W*H)
- Length: Reel
- Working Voltage: DC24V
- LED: Epistar SMD LEDs
- LED QTY: 48LEDs/M
- Power: 18W
- Colors: Warm White(3000K), Natural White(4000K), Cool White(6500K)
- Beam Angle: 30°，45°，60°，20°45°
- CRI: ＞
- Lumen/M: 1851lm-1949lm
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The waterproof LED wall washer light strips can replace the traditional wall washer lights, with a small size and lightweight, easy to install, and light up. Landscape applications can be installed in wet, damp, or water locations. The wall light strips work in DC24V for a higher safety factor, use high-quality Epistar SMD LEDs as the light source, and have 48 LEDs per meter. The LEDs are sealed in a TPU tube and filled and sealed with PU glue to resist yellowing, high temperature, corrosion, weak acid, alkali, and high flexibility. They have strong adhesion, good durability, and high reliability. The installer can choose the various beam angle lenses for different applications, the installer can choose 30°， 45°，60°, and 20°45°. The wall washer strips are cuttable; the installer can cut and reconnect them for your lighting project.
Specifications
Size: 18.5*9.5mm(W*H)
Length: Reel
Working Voltage: DC24V
LED: Epistar SMD LEDs
LED QTY: 48LEDs/M
Power: 18W
Colors: Warm White(3000K), Natural White(4000K), Cool White(6500K)
Beam Angle: 30°，45°，60°，20°45°
CRI: ＞
Lumen/M: 1851lm-1949lm
Luminous Efficacy(LM/W): 116
Bending Diameter: 100mm
Cutting Size: 125mm
IP Rating: IP67
Dimmable: YES
Working Temperature: -25℃-+45℃
Includes
1 * White Waterproof LED Wall Washer Light Strips
Silicone LED Clips
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
