Product details
27W RGB+CCT Underwater Pool Lights
LumaCircuit offers 27W RGB+CCT Underwater Pool Lights as a configurable surface light for project builds. Typical applications include CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. wireless controller User Manual Material: 316 Stainless Steel + PC Input Voltage: AC12V/-24V The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- The wireless controller 27W underwater pool lights are an energy-efficient and cost-effective way to light up your pool. These lights feature a color-changing design, allowing you to create different lighting effects in your pool. They are made of 316 stainless steel for better corrosion resistance and do not easily fade. Use the high-lumen LED chips as the light source for low power consumption and low light failure.
- wireless controller User Manual
- Material: 316 Stainless Steel + PC
- Input Voltage: AC12V/-24V
- Emitting Colors: RGB + CCT
- Color Temperature: 2700 K- 6500 K
- Light Efficiency: 75LM/W
- 16 Million Colors Available And CCT, Brightness, And Saturation Adjustable
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 12 V / 12-24 V
- Light engine: RGB+CCT
- Material: 316 Stainless Steel + PC
- LumaCircuit model: LC-SUR-IV8KLA
- Diameter: Φ300mm
- Height: 70mm
- Input Voltage: AC12V/-24V
- Power: 27W
- Emitting Colors: RGB + CCT
- Color Temperature: 2700 K- 6500 K
- Beam Angle: 160°
- IP Rate: IP68
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around CCT and RGB+CCT rooms, Retrofit dimming, Home Assistant lighting zones. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
The wireless controller 27W underwater pool lights are an energy-efficient and cost-effective way to light up your pool. These lights feature a color-changing design, allowing you to create different lighting effects in your pool. They are made of 316 stainless steel for better corrosion resistance and do not easily fade. Use the high-lumen LED chips as the light source for low power consumption and low light failure. The surface has a high-quality PC cover for strong hardness, high light-transmitting rate, and wide illumination distance. The silicone rubber sealing and resin potting inside ensure excellent waterproofing and a waterproof level reaching IP68. The installer can install them underwater as pool lights, pond lights, fountain lights, underwater dock lighting, etc. The back is with a wall-mounted design, making it easy to install. The wireless controller underwater light works in AC12V or -24V, which is safe for kids and pets. A remote control can control it and has a control distance of up to 50 meters. After pairing with a gateway, it can be controlled by a smartphone APP and third-party voice, including Amazon Alexa and Google Assistant. There are 16 million colors and 9 dynamic modes available. The installer can adjust the saturation, brightness, and color temperature for various scenes from 2700K to 6500 K.
Quick Links
wireless controller User Manual
Specifications
Material: 316 Stainless Steel + PC
Model
Diameter: Φ300mm
Height: 70mm
Input Voltage: AC12V/-24V
Power: 27W
Emitting Colors: RGB + CCT
Color Temperature: 2700 K- 6500 K
Luminous Flux: 2000lm
Light Efficiency: 75LM/W
16 Million Colors Available And CCT, Brightness, And Saturation Adjustable
9 Dynamic Modes Available And Speed Adjustable
Beam Angle: 160°
IP Rate: IP68
RF: (LoRa)
Modulation Method: LoRa Spread Spectrum
Control Distance: 50m(Lamps Into 0.5m Water)
Remote Controller Control
Smartphone APP Control And Third-Party Voice Control
Working Temperature: -20℃-+45℃
Includes
1 * wireless controller 27W Underwater Pool Light
Product resources
Technical documents
Typical applications
- CCT and RGB+CCT rooms
- Retrofit dimming
- Home Assistant lighting zones
