4G WiFi RGB+CCT GU10 Bulb
LumaCircuit offers 4G WiFi RGB+CCT GU10 Bulb as a configurable bulb for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Acrylic Transmitting Cover Input Voltage: -240V; 50/60Hz Color: RGB+CCT, RGB, Selected CCT The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- wireless controller RGBWW GU10 Bulb Manual
- Acrylic Transmitting Cover
- Input Voltage: -240V; 50/60Hz
- Color: RGB+CCT, RGB, Selected CCT
- Color Temperature: 2700K-6500K
- Luminous Efficiency: 70LM/W
- Equivalency: 34 Watt Halogen
- IP Rating: Non-waterproof
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: RGB+CCT
- Size: 57*50mm(H*W)
- Base: GU10
- Input Voltage: -240V; 50/60Hz
- Power: 4W
- Color: RGB+CCT, RGB, Selected CCT
- Color Temperature: 2700K-6500K
- Current Draw: 0.07A
- IP Rating: Non-waterproof
- CRI: >
- Beam Angle: 25°
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
Quick Links
wireless controller RGBWW GU10 Bulb Manual
Specifications
Size: 57*50mm(H*W)
Base: GU10
Acrylic Transmitting Cover
Input Voltage: -240V; 50/60Hz
Power: 4W
Color: RGB+CCT, RGB, Selected CCT
Color Temperature: 2700K-6500K
Luminous Flux: 280LM
Luminous Efficiency: 70LM/W
Current Draw: 0.07A
Equivalency: 34 Watt Halogen
IP Rating: Non-waterproof
CRI: >
PF: >0.55
Beam Angle: 25°
RF: 2.
Control Distance: 30m
Dimmable: YES
16 Million Colors Available
Color Temperature, Brightness, And Saturation Adjustable
4G WiFi Transmission Technology
4G Remote Control And Phone APP Control
Supports Third-Party Voice Control
Signal Transmitting And Modes Synchronization
Compatible With 2.4 GHz wireless And wireless controller RGB CCT Remote Controls T4, WL- 2.4G Gateway
Supported Smart Phone App: wireless controller
Fit For Bedroom, Restaurant, Sitting Room, Cookroom
Includes
1 * wireless controller RGB CCT GU10 Bulb
Product resources
Technical documents
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
