6W RGB+CCT Waterproof LED Downlight Spot
LumaCircuit offers 6W RGB+CCT Waterproof LED Downlight Spot as a configurable downlight for project builds. Typical applications include Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Input Voltage: -240V, 50/60Hz Emitting Color: RGB + CCT Color Temperature Adjustable: 2700 K- 6500 K The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering. Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination. For a project brief, include the selected voltage, dimensions, driver and control details so the configuration can be reviewed efficiently.
Product features
The following details summarize the physical characteristics and configuration options for this product. Use the selected variant and production drawing to finalize dimensions and electrical details.
- wireless controller Instruction
- Input Voltage: -240V, 50/60Hz
- Emitting Color: RGB + CCT
- Color Temperature Adjustable: 2700 K- 6500 K
- 16 Million Colors Available And Saturation, Brightness, And Color Temperature Adjustable
- 9 Dynamic Modes Available, Brightness, Saturation, And Color-Changing Speed Adjustable
- 4G RF Remote Controllable T4, T3, WL
- Support Smartphone APP Control And Third-Party Voice Control(Amazon Alexa And Google Assistant)(2.4G Gateway Needed)
Configuration and technical detail
To configure this product, specify the LumaCircuit SKU, required voltage, light engine, dimensions or cutout, driver/controller and finish or protection variant. The technical rows below summarize the physical and electrical details for this product family. Confirm the selected configuration against the production drawing before ordering.
- Input: 240 V
- Light engine: RGB+CCT
- Material: Aluminum
- LumaCircuit model: LC-DL-TFAXXL
- Size: Φ108*52mm
- Hole Size: Φ100mm
- Input Voltage: -240V, 50/60Hz
- Power: 6W
- Emitting Color: RGB + CCT
- Color Temperature Adjustable: 2700 K- 6500 K
- 2.4G RF Remote Controllable: T4, T3, WL
- CRI: >
Control and installation
Use this product on the everyday Zigbee route. A Zigbee gateway or coordinator is required, and ZHA, Zigbee2MQTT and Tuya Gateway must be validated as separate paths on the exact driver, controller and firmware combination.
Plan the installation around Everyday room lighting, Kitchen and cabinet task light, Retail and commercial fit-outs. Keep power, signal, heat path, access and service joints visible in the drawing.
Configuration support
Pricing follows the selected setup. Share the required voltage, dimensions or cutout, light engine, driver/controller and finish or protection option so the product can be specified accurately.
Product overview
Quick Links
wireless controller Instruction
Specifications
Material: Aluminum
Model
Size: Φ108*52mm
Hole Size: Φ100mm
Input Voltage: -240V, 50/60Hz
Power: 6W
Emitting Color: RGB + CCT
Color Temperature Adjustable: 2700 K- 6500 K
16 Million Colors Available And Saturation, Brightness, And Color Temperature Adjustable
9 Dynamic Modes Available, Brightness, Saturation, And Color-Changing Speed Adjustable
4G RF Remote Controllable T4, T3, WL
Support Smartphone APP Control And Third-Party Voice Control(Amazon Alexa And Google Assistant)(2.4G Gateway Needed)
Luminous Flux: 500LM
Light Efficiency: 80LM/W
CRI: >
Beam Angle: 120°
RF: 2.
Control Distance: <30M
Waterproof Level: IP54
Auto Signal Transmitting And Modes Synchronization
Working Temperature: -20℃-+60℃
Includes
1 * 2.4G Remote Control wireless controller Downlight Spot
Product resources
Technical documents
Typical applications
- Everyday room lighting
- Kitchen and cabinet task light
- Retail and commercial fit-outs
